Page #95 background image
PurposeCommand or Action
Returns the router to policy map configuration mode.exit
Example:
RP/0/RSP0/CPU0:router(config-pmap)# exit
Step 8
Ends the policy map configuration.end-policy-map
Example:
RP/0/RSP0/CPU0:router(config-pmap)# end-policy-map
Step 9
Configures an interface and enters the interface
configuration mode.
interface type interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# interface TenGigE
0/1/0/0
Step 10
Enters the satellite network virtualization (nV)
configuration submode.
nv
Example:
RP/0/RSP0/CPU0:router(config-if)# nv
Step 11
Specifies an interface as an Interface Control Plane
Extender(ICPE) inter-chassis link (ICL).
satellite-fabric-link satellite satellite_id
Example:
RP/0/RSP0/CPU0:router(config-if-nV)#
satellite-fabric-link satellite 100
Step 12
The Interface Control Plane Extender(ICPE)
infrastructure has a mechanism to provide the
Control Plane of an interface physically located
on the Satellite device in the local Cisco IOS
XR software.
Note
Configures the remote satellite ports 0 to 9.
remote-ports interface_type remote_subslot
Example:
RP/0/RSP0/CPU0:router(config-satellite-fabric-link)#
remote-ports Satellite-Ether 0/0/0-9
Step 13
Attaches a policy map to an output interface to be used
as the service policy for that interface.
service-policy output policy-map
Example:
RP/0/RSP0/CPU0:router(config-satellite-fabric-link)#
service-policy output policy3
Step 14
commit
Step 15
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
85
Configuring QoS on the Satellite System
Offloading Service-policy on Physical Satellite Fabric Link
