Cisco ASR 9000 Series System Configuration Guide

PurposeCommand or Action
Specifies service (QoS) group values in a class map to
match packets.
match qos-group [qos-group-value]
Example:
RP/0/RSP0/CPU0:router(config-cmap)# match qos-group
5
Step 3
•
qos-group-value identifier argument is specified
as the exact value or range of values from 0 to
63.
•
Up to eight values (separated by spaces) can be
entered in one match statement.
•
match qos-groupcommand is supported only for
an egress policy.
Ends the class map configuration.end-class-map
Example:
RP/0/RSP0/CPU0:router(config-cmap)# end-class-map
Step 4
Creates or modifies a policy map that can be attached
to one or more interfaces to specify a service policy
and enters the policy map configuration mode.
policy-map [ type qos ] policy-name
Example:
RP/0/RSP0/CPU0:router(config)# policy-map policy4
Step 5
Specifies the name of the class whose policy you want
to create or change.
class class-name
Example:
RP/0/RSP0/CPU0:router(config-pmap)# class class4
Step 6
Specifies the bandwidth allocated for a class belonging
to a policy map.
bandwidth {bandwidth [units] | percent value}
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# bandwidth
percent 13
Step 7
Returns the router to policy map configuration mode.exit
Example:
RP/0/RSP0/CPU0:router(config-pmap)# exit
Step 8
Ends the policy map configuration.end-policy-map
Example:
RP/0/RSP0/CPU0:router(config-pmap)# end-policy-map
Step 9
Configures an interface and enters the interface
configuration mode.
interface type interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# interface Bundle-Ether
2
Step 10
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
87
Configuring QoS on the Satellite System
Offloading Service-policy on Bundle SFL
