12-33
Catalyst 2960 and 2960-S Switches Software Configuration Guide, Release 15.0(1)SE
OL-26520-01
Chapter 12 Configuring Interface Characteristics
Configuring Ethernet Interfaces
Switch(config-if)# end
Configuring a Power Management Mode on a PoE Port
Note PoE commands are supported only when the switch is running the LAN base image. Power over Ethernet
Plus (PoE+) is supported only on Catalyst 2960-S switches.
For most situations, the default configuration (auto mode) works well, providing plug-and-play
operation. No further configuration is required. However, use the following procedure to give a PoE port
higher priority, to make it data only, or to specify a maximum wattage to disallow high-power powered
devices on a port.
Note When you make PoE configuration changes, the port being configured drops power. Depending on the
new configuration, the state of the other PoE ports, and the state of the power budget, the port might not
be powered up again. For example, port 1 is in the auto and on state, and you configure it for static mode.
The switch removes power from port 1, detects the powered device, and repowers the port. If port 1 is
in the auto and on state and you configure it with a maximum wattage of 10 W, the switch removes power
from the port and then redetects the powered device. The switch repowers the port only if the powered
device is a Class 1, Class 2, or a Cisco-only powered device.
Beginning in privileged EXEC mode, follow these steps to configure a power management mode on a
PoE-capable port:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the physical port to be configured, and enter interface
configuration mode.
