Cisco CATALYST 2960

33-27
Catalyst 2960 and 2960-S Switches Software Configuration Guide, Release 15.0(1)SE
OL-26520-01
Chapter 33 Configuring QoS
Configuring Auto-QoS
The switch automatically maps
DSCP values to an egress queue
and to a threshold ID.
Switch(config)# no mls qos srr-queue
output dscp-map
Switch(config)# mls qos srr-queue
output dscp-map queue 1 threshold 3
40 41 42 43 44 45 46 47
Switch(config)# mls qos srr-queue
output dscp-map queue 2 threshold 3
24 25 26 27 28 29 30 31
Switch(config)# mls qos srr-queue
output dscp-map queue 2 threshold 3
48 49 50 51 52 53 54 55
Switch(config)# mls qos srr-queue
output dscp-map queue 2 threshold 3
56 57 58 59 60 61 62 63
Switch(config)# mls qos srr-queue
output dscp-map queue 3 threshold 3
16 17 18 19 20 21 22 23
Switch(config)# mls qos srr-queue
output dscp-map queue 3 threshold 3
32 33 34 35 36 37 38 39
Switch(config)# mls qos srr-queue
output dscp-map queue 4 threshold 1 8
Switch(config)# mls qos srr-queue
output dscp-map queue 4 threshold 2 9
10 11 12 13 14 15
Switch(config)# mls qos srr-queue
output dscp-map queue 4 threshold 3 0
1 2 3 4 5 6 7
Switch(config)# no mls qos srr-queue
output dscp-map
Switch(config)# mls qos srr-queue
output dscp-map queue 1 threshold 3 32
33 40 41 42 43 44 45 46 47
Switch(config)# mls qos srr-queue
output dscp-map queue 2 threshold 1 16
17 18 19 20 21 22 23
Switch(config)# mls qos srr-queue
output dscp-map queue 2 threshold 1 26
27 28 29 30 31 34 35 36 37 38 39
Switch(config)# mls qos srr-queue
output dscp-map queue 2 threshold 2 24
Switch(config)# mls qos srr-queue
output dscp-map queue 2 threshold 3 48
49 50 51 52 53 54 55 56
Switch(config)# mls qos srr-queue
output dscp-map queue 2 threshold 3 57
58 59 60 61 62 63
Switch(config)# mls qos srr-queue
output dscp-map queue 3 threshold 3 0
1 2 3 4 5 6 7
Switch(config)# mls qos srr-queue
output dscp-map queue 4 threshold 1 8
9 11 13 15
Switch(config)# mls qos srr-queue
output dscp-map queue 4 threshold 2 10
12 14
Table 33-5 Generated Auto-QoS Configuration (continued)
Description Automatically Generated Command {voip}
Enhanced Automatically Generated
Command{Video|Trust|Classify}
