Chapter 33 Configuring QoS
Configuring Auto-QoS
The switch automatically sets up
the ingress queues, with queue 2
as the priority queue and queue 1
in shared mode. The switch also
configures the bandwidth and
buffer size for the ingress queues.
Note Catalyst 2960-S switches
do not support ingress
queueing.
Switch(config)# no mls qos srr-queue
input priority-queue 1
Switch(config)# no mls qos srr-queue
input priority-queue 2
Switch(config)# mls qos srr-queue
input bandwidth 90 10
Switch(config)# mls qos srr-queue
input threshold 1 8 16
Switch(config)# mls qos srr-queue
input threshold 2 34 66
Switch(config)# mls qos srr-queue
input buffers 67 33
Switch(config)# no mls qos srr-queue
input priority-queue 1
Switch(config)# no mls qos srr-queue
input priority-queue 2
Switch(config)# mls qos srr-queue
input bandwidth 70 30
Switch(config)# mls qos srr-queue
input threshold 1 80 90
Switch(config)# mls qos srr-queue
input priority-queue 2 bandwidth 30
The switch automatically
configures the egress queue
buffer sizes. It configures the
bandwidth and the SRR mode
(shaped or shared) on the egress
queues mapped to the port.
Switch(config)# mls qos queue-set
output 1 threshold 1 138 138 92 138
Switch(config)# mls qos queue-set
output 1 threshold 2 138 138 92 400
Switch(config)# mls qos queue-set
output 1 threshold 3 36 77 100 318
Switch(config)# mls qos queue-set
output 1 threshold 4 20 50 67 400
Switch(config)# mls qos queue-set
output 2 threshold 1 149 149 100 149
Switch(config)# mls qos queue-set
output 2 threshold 2 118 118 100 235
Switch(config)# mls qos queue-set
output 2 threshold 3 41 68 100 272
Switch(config)# mls qos queue-set
output 2 threshold 4 42 72 100 242
Switch(config)# mls qos queue-set
output 1 buffers 10 10 26 54
Switch(config)# mls qos queue-set
output 2 buffers 16 6 17 61
Switch(config-if)# priority-queue out
Switch(config-if)# srr-queue
bandwidth share 10 10 60 20
Switch(config)# mls qos queue-set
output 1 threshold 2 100 100 50 200
Switch(config)# mls qos queue-set
output 1 threshold 2 125 125 100 400
Switch(config)# mls qos queue-set
output 1 threshold 3 100 100 100 400
Switch(config)# mls qos queue-set
output 1 threshold 4 60 150 50 200
Switch(config)# mls qos queue-set
output 1 buffers 15 25 40 20
Table 33-5 Generated Auto-QoS Configuration (continued)
Description Automatically Generated Command {voip}
Enhanced Automatically Generated
Command{Video|Trust|Classify}
