2-143
Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0
78-18663-01
Chapter 2 Alarm Troubleshooting
Alarm Procedures
An SLMF UNEQ low-order path alarm alarm indicates that the node is receiving SDH path overhead
with Bits 5, 6, and 7 of the V5 overhead byte all set to zeroes. The source of the problem is not the node
raising the alarm, but the node transmitting the VC signal to it. The V in SLMF UNEQ low-order path
alarm indicates that the failure has occurred at the VC layer.
Warning
Invisible laser radiation could be emitted from the end of the unterminated fiber cable or connector.
Do not stare into the beam directly with optical instruments. Viewing the laser output with certain
optical instruments (for example, eye loupes, magnifiers, and microscopes) within a distance of
100 mm could pose an eye hazard.
Statement 1056
Warning
Use of controls, adjustments, or performing procedures other than those specified could result in
hazardous radiation exposure.
Statement 1057
Clear the LP-UNEQ Alarm
Step 1 Complete the “Clear the HP-UNEQ Alarm” procedure on page 2-141.
Caution Always use the supplied electrostatic discharge wristband when working with a powered
ONS 15310-MA SDH.
Step 2 If the alarm does not clear, log into the Technical Support Website at
http://www.cisco.com/cisco/web/support/index.html for more information or call Cisco TAC
(1-800-553-2447) in order to report a Service-Affecting (SA) problem.
2.7.232 UNQUAL-PPM
Default Severity: Not Reported (NR), Non-Service-Affecting (NSA)
SDH Logical Objects: PPM
The Unqualified PPM Inserted condition occurs when a PPM with a nonqualified product ID is plugged
into the card’s port; that is, the PPM passes the security code check as a Cisco PPM but is not qualified
for use on the particular card.
Clear the UNQUAL-PPM Condition
Step 1 Obtain the correct Cisco PPM and replace the existing PPM with the new one.
Step 2 If the condition does not clear, log into the Technical Support Website at
http://www.cisco.com/cisco/web/support/index.html for more information or call Cisco TAC
(1-800-553-2447).
