2-60
Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0
78-18663-01
Chapter 2 Alarm Troubleshooting
Alarm Procedures
2.7.67 FE-EQPT-NSA
Default Severity: Not Alarmed (NA), Non-Service-Affecting (NSA)
SDH Logical Object: DS3
The Far End Common Equipment Failure condition occurs when a Non-Service-Affecting (NSA)
equipment failure is detected on a far-end 15310-MA SDH CTX, E1-21/DS3-E3-3, or E1-63/DS3-E3-3
E1 port.
Clear the FE-EQPT-NSA Condition
Step 1 To troubleshoot an FE condition, determine which node and port link directly to the card reporting the
FE condition.
Step 2 Log into the node that links directly to the port reporting the FE condition.
Step 3 Clear the main alarm. Refer to the appropriate alarm section in this chapter for troubleshooting
instructions.
Step 4 If the condition does not clear, log into the Technical Support Website at
http://www.cisco.com/cisco/web/support/index.html for more information or call Cisco TAC
(1-800-553-2447).
2.7.68 FE-FRCDWKSWBK-SPAN
Default Severity: Not Alarmed (NA), Non-Service-Affecting (NSA)
SDH Logical Object: STM
The Far End Forced Switch Back to Working—Span condition is raised on a far-end 1+1/LMSP protect
port when it is Force switched to the working port.
Note WKSWBK-type conditions apply only to nonrevertive circuits.
Clear the FE-FRCDWKSWBK-SPAN Condition
Step 1 Complete the “Clear a 1+1/LMSP Force or Manual Switch Command” section on page 2-147 for the
far-end port.
If the condition does not clear, log into the Technical Support Website at
http://www.cisco.com/cisco/web/support/index.html for more information or call Cisco TAC (1 800
553-2447).
2.7.69 FE-FRCDWKSWPR-SPAN
The FE-FRCDWKSWPR-SPAN condition is not used in the ONS 15310 platforms in this release. It is
reserved for development.
