2-48
Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0
78-18663-01
Chapter 2 Alarm Troubleshooting
Alarm Procedures
Clear the DUP-NODENAME Alarm
Step 1 In node view, click the Provisioning > General tabs.
Step 2 In the Node Name/TID field, enter a unique name for the node.
Step 3 Click Apply.
Step 4 If the alarm does not clear, log into the Technical Support Website at
http://www.cisco.com/cisco/web/support/index.html for more information or call Cisco TAC
(1-800-553-2447).
2.7.49 DUP-SHELF-ID
For information about this alarm or condition, refer to the “Alarm Troubleshooting” chapter in the
Cisco ONS 15454 DWDM Troubleshooting Guide. That guide discusses all DWDM alarms.
2.7.50 EHIBATVG
Default Severity: Major (MJ), Service-Affecting (SA)
SDH Logical Object: PWR
The Extreme High Voltage Battery alarm occurs in a –48 VDC environment when a battery lead input
voltage exceeds the extreme high power threshold.
This preset value is approximately -56 VDC for the Cisco ONS 15310-CL hardware platforms versions
800-24012-08 and before and approximately -58 VDC for versions 800-24012-09 and later. Also, the
extreme high voltage batter value is approximately -54 VDC for CTX version of the Cisco ONS 15310-
MA hardware versions 800-23879-04 and before and is approximately -58 VDC for CTX version of the
Cisco ONS 15310-MA hardware version 800-23879-05 and later. The alarm is raised until the voltage
remains under the threshold for 120 seconds.
Clear the EHIBATVG Alarm
Step 1 The problem is external to the ONS 15310-MA SDH. Troubleshoot the power source supplying the
battery leads.
Step 2 If the alarm does not clear, log into the Technical Support Website at
http://www.cisco.com/cisco/web/support/index.html for more information or call Cisco TAC
(1-800-553-2447) in order to report a Service-Affecting (SA) problem.
2.7.51 ELWBATVG
Default Severity: Major (MJ), Service-Affecting (SA)
SDH Logical Object: PWR
