Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0
78-18663-01
Chapter 2 Alarm Troubleshooting
Alarm List by Logical Object Type
2.4 Alarm List by Logical Object Type
Table 2-8 lists all ONS 15310-MA SDH Release 9.0 alarms and logical objects as they are given in the
system alarm profile. The list entries are organized by logical object name and then by alarm or condition
name. Where appropriate, the alarm entries also contain troubleshooting procedures.
Note The list is given here exactly as it is shown in CTC, and in some cases does not follow alphabetical order.
VCMON-LP
VC alarm detection at monitor point (downstream from the cross-connect).
Note The network element reports alarms or conditions on ingress ports of the
card. Alarms detected at the internal ports (TERM side) will be ingress
mapped to the MON side. The alarm profile entities of VCMON-LP, if
available, should be changed to the same severity as the customized
severity for a specific VCMON-LP alarm.
VCG
Virtual concatenation group.
VCTRM-HP VC alarm detection at the termination point (upstream from the cross-connect).
Note The network element reports alarms or conditions on ingress ports of the
card. Alarms detected at the internal ports (TERM side) will be ingress
mapped to the MON side. The alarm profile entities of VCTRM-HP, if
available, should be changed to the same severity as the customized
severity for a specific VCTRM-HP alarm.
VCTRM-LP
VC alarm detection at termination (downstream from the cross-connect).
Note The network element reports alarms or conditions on ingress ports of the
card. Alarms detected at the internal ports (TERM side) will be ingress
mapped to the MON side. The alarm profile entities of VCTRM-LP, if
available, should be changed to the same severity as the customized
severity for a specific VCTRM-LP alarm.
Table 2-7 Alarm Logical Object Type Definitions (continued)
Type Definition
Table 2-8 ONS 15310-MA SDH Alarm List by Logical Object as Shown in Alarm Profile
BITS: AIS (NR) EQPT: PWR-FAIL-B (MN) STM: SSM-PRC (NA)
BITS: LOF (MN) EQPT: RUNCFG-SAVENEED (NA) STM: SSM-PRC (NA)
BITS: LOS (MN) EQPT: SFTWDOWN (MN) STM: SSM-RES (NA)
BITS: SSM-DUS (NA) EQPT: SW-MISMATCH (NA) STM: SSM-SDH-TN (NA)
BITS: SSM-FAIL (MN) EQPT: SWMTXMOD-PROT (CR) STM: SSM-SETS (NA)
BITS: SSM-LNC (NA) EQPT: SWMTXMOD-WORK (CR) STM: SSM-TNC (NA)
BITS: SSM-OFF (NA) EQPT: WKSWPR (NA) STM: SYNC-FREQ (NA)
BITS: SSM-PRC (NA) EQPT: WTR (NA) STM: TIM (CR)
BITS: SSM-PRC (NA) EXT-SREF: FRCDSWTOPRI (NA) STM: RS-TIM (CR)
BITS: SSM-RES (NA) EXT-SREF: FRCDSWTOSEC (NA) STM: WKSWPR (NA)
