Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0
78-18663-01
Chapter 2 Alarm Troubleshooting
Alarm List by Logical Object Type
BITS: SSM-SDH-TN (NA) EXT-SREF: FRCDSWTOTHIRD (NA) STM: WTR (NA)
BITS: SSM-SETS (NA) EXT-SREF: MANSWTOPRI (NA) PPM: AS-CMD (NA)
BITS: SSM-TNC (NA) EXT-SREF: MANSWTOSEC (NA) PPM: AS-MT (NA)
BITS: SYNC-FREQ (NA) EXT-SREF: MANSWTOTHIRD (NA) PPM: EQPT (CR)
BPLANE: AS-CMD (NA) EXT-SREF: SWTOPRI (NA) PPM: HI-LASERBIAS (MN)
BPLANE: INVMACADR (MJ) EXT-SREF: SWTOSEC (NA) PPM: HI-LASERTEMP (MN)
BPLANE: MFGMEM (CR) EXT-SREF: SWTOTHIRD (NA) PPM: HI-TXPOWER (MN)
CE100T: AS-CMD (NA) EXT-SREF: SYNCPRI (MN) PPM: IMPROPRMVL (CR)
CE100T: AS-MT (NA) EXT-SREF: SYNCSEC (MN) PPM: LO-LASERBIAS (MN)
CE100T: CARLOSS (MJ) EXT-SREF: SYNCTHIRD (MN) PPM: LO-LASERTEMP (MN)
CE100T: DATA-CRC (MJ) FAN: EQPT-MISS (CR) PPM: LO-TXPOWER (MN)
CE100T: GFP-CSF (MJ) FAN: FAN (CR) PPM: MEA (CR)
CE100T: GFP-LFD (MJ) FAN: FANDEGRADE (MJ) PPM: MFGMEM (CR)
CE100T: GFP-UP-MISMATCH (MJ) FAN: MEA (CR) PPM: NON-CISCO-PPM (NR)
CE100T: LPBKFACILITY (NA) FAN: MFGMEM (CR) PPM: PROV-MISMATCH (MN)
CE100T: LPBKTERMINAL (NA) FUDC: AIS (NR) PPM: UNQUAL-PPM (NR)
CE100T: TPTFAIL (MJ) FUDC: LOS (MN) PWR: AS-CMD (NA)
CEMR: AS-CMD (NA) ML100T: AS-CMD (NA) PWR: BAT-FAIL (MJ)
CEMR: AS-MT (NA) ML100T: AS-MT (NA) PWR: EHIBATVG (MJ)
CEMR: CARLOSS (MJ) ML100T: CARLOSS (MJ) PWR: ELWBATVG (MJ)
CEMR: GFP-CSF (MJ) ML100T: DATA-CRC (MJ) RPRIF: RPR-PASSTHR (NA)
CEMR: GFP-LFD (MJ) ML100T: GFP-CSF (MJ) SHELF: AS-CMD (NA)
CEMR: GFP-UP-MISMATCH (MJ) ML100T: GFP-LFD (MJ) SHELF: AS-MT (NA)
CEMR: LPBKFACILITY (NA) ML100T: GFP-UP-MISMATCH (MJ) SHELF: DUP-SHELF-ID (MJ)
CEMR: LPBKTERMINAL (NA) ML100T: LINK-KEEPALIVE (CR) SHELF: MEA (MJ)
CEMR: PORT-MISMATCH (MJ) ML100T: RPRW (NA) SHELF: SHELF-COMM-FAIL (MJ)
CEMR: TPTFAIL (MJ) ML100T: TPTFAIL (MJ) VCMON-HP: AU-AIS (NR)
E1: AIS (NR) NE: APC-END (NA) VCMON-HP: AUTOSW-AIS-SNCP
(NR)
E1: AS-CMD (NA) NE: AS-CMD (NA) VCMON-HP: AUTOSW-LOP-SNCP
(NA)
E1: AS-MT (NA) NE: AUD-LOG-LOSS (NA) VCMON-HP: AUTOSW-SDBER-SNCP
(NA)
E1: IDLE (NA) NE: AUD-LOG-LOW (NA) VCMON-HP: AUTOSW-SFBER-SNCP
(NA)
E1: LOF (MJ) NE: DATAFLT (MN) VCMON-HP: AUTOSW-UNEQ-SNCP
(NA)
E1: LOS (MJ) NE: DUP-IPADDR (MN) VCMON-HP: FAILTOSW-HO (NA)
Table 2-8 ONS 15310-MA SDH Alarm List by Logical Object as Shown in Alarm Profile (continued)
