2-66
Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0
78-18663-01
Chapter 2 Alarm Troubleshooting
Alarm Procedures
Note FSTSYNC is an informational condition. It does not require troubleshooting.
2.7.86 FULLPASSTHR-BI
The FULLPASSTHR-BI condition is not used in the ONS 15310 platforms in this release. It is reserved
for development.
2.7.87 GFP-CSF
Default Severity: Major (MJ), Service-Affecting (SA)
SDH Logical Objects: CE100T, CEMR, ML100T
The GFP Client Signal Fail Detected alarm is a secondary alarm raised on local GFP data ports when a
remote Service-Affecting (SA) alarm causes invalid data transmission. The alarm is raised locally on
CE-Series and ML-100T-8 Ethernet ports and does not indicate that a Service-Affecting (SA) failure is
occurring at the local site, but that a CARLOSS, LOS, or SYNCLOSS alarm is affecting a remote data
port’s transmission capability. For more information about Ethernet cards, refer to the
Cisco ONS 15310-CL and Cisco ONS 15310-MA Ethernet Card Software Feature and Configuration
Guide.
Clear the GFP-CSF Alarm
Step 1 Clear the Service-Affecting (SA) alarm at the remote data port.
Step 2 If the GFP-CSF alarm does not clear, log into the Technical Support Website at
http://www.cisco.com/cisco/web/support/index.html for more information or call Cisco TAC
(1-800-553-2447) to report a Service-Affecting (SA) problem.
2.7.88 GFP-EX-MISMATCH
Default Severity: Major (MJ), Service-Affecting (SA)
Logical Object: CE100T
The GFP Extension Header Mismatch alarm is raised on Fibre Channel/fiber connectivity (FICON) GFP
ports when it receives frames with an extension header that is not null. The alarm occurs when a
provisioning error causes all GFP frames to be dropped for 2.5 seconds. To clear this alarm, ensure that
both end ports are sending a null extension header for a GFP frame.
Note For more information about Ethernet cards, refer to the Cisco ONS 15310-CL and Cisco ONS 15310-MA
Ethernet Card Software Feature and Configuration Guide.
