Cisco ONS 15310-MA SDH Troubleshooting Guide, Release 9.0
78-18663-01
Chapter 2 Alarm Troubleshooting
Alarm List by Logical Object Type
E1: LPBKDS1FE-CMD (NA) NE: DUP-NODENAME (MN) VCMON-HP: FORCED-REQ (NA)
E1: LPBKFACILITY (NA) NE: ETH-LINKLOSS (NA) VCMON-HP: LOCKOUT-REQ (NA)
E1: LPBKTERMINAL (NA) NE: HITEMP (CR) VCMON-HP: LOM (CR)
E1: RAI (NA) NE: I-HITEMP (CR) VCMON-HP: AU-LOP (CR)
E1: SD (NA) NE: INTRUSION-PSWD (NA) VCMON-HP: LPBKCRS (NA)
E1: SF (NA) NE: SNTP-HOST (MN) VCMON-HP: MAN-REQ (NA)
E1: SSM-DUS (NA) NE: SYSBOOT (MJ) VCMON-HP: LP-PLM (CR)
E1: SSM-FAIL (MN) NE-SREF: FRCDSWTOINT (NA) VCMON-HP: HP-RFI (NR)
E1: SSM-OFF (NA) NE-SREF: FRCDSWTOPRI (NA) VCMON-HP: ROLL (NA)
E1: SSM-PRC (NA) NE-SREF: FRCDSWTOSEC (NA) VCMON-HP: ROLL-PEND (NA)
E1: SSM-RES (NA) NE-SREF: FRCDSWTOTHIRD (NA) VCMON-HP: HP-DEG (NA)
E1: SYNC-FREQ (NA) NE-SREF: FRNGSYNC (NA) VCMON-HP: HP-EXC (NA)
E1: TX-AIS (NR) NE-SREF: FSTSYNC (NA) VCMON-HP: HP-TIM (MN)
E1: TX-IDLE (NA) NE-SREF: HLDOVRSYNC (NA) VCMON-HP: WTR (NA)
E1: TX-LOF (NR) NE-SREF: MANSWTOINT (NA) VCTRM-HP: AU-AIS (NR)
E1: TX-RAI (NA) NE-SREF: MANSWTOPRI (NA) VCTRM-HP: AS-MT-OOG (NA)
DS3: AIS (NR) NE-SREF: MANSWTOSEC (NA) VCTRM-HP: ENCAP-MISMATCH-P
(CR)
DS3: AS-CMD (NA) NE-SREF: MANSWTOTHIRD (NA) VCTRM-HP: LCAS-CRC (NA)
DS3: AS-MT (NA) NE-SREF: SSM-LNC (NA) VCTRM-HP: LCAS-RX-DNU (NA)
DS3: DS3-MISM (NA) NE-SREF: SSM-PRC (NA) VCTRM-HP: LCAS-RX-FAIL (NA)
DS3: FE-AIS (NA) NE-SREF: SSM-PRC (NA) VCTRM-HP: LCAS-RX-GRP-ERR
(NA)
DS3: FE-DS3-NSA (NA) NE-SREF: SSM-RES (NA) VCTRM-HP: LCAS-TX-ADD (NA)
DS3: FE-DS3-SA (NA) NE-SREF: SSM-SDH-TN (NA) VCTRM-HP: LCAS-TX-DNU (NA)
DS3: FE-EQPT-NSA (NA) NE-SREF: SSM-SETS (NA) VCTRM-HP: LOF (CR)
DS3: FE-IDLE (NA) NE-SREF: SSM-TNC (NA) VCTRM-HP: LOM (CR)
DS3: FE-LOF (NA) NE-SREF: SWTOPRI (NA) VCTRM-HP: AU-LOP (CR)
DS3: FE-LOS (NA) NE-SREF: SWTOSEC (NA) VCTRM-HP: LPBKCRS (NA)
DS3: INC-ISD (NA) NE-SREF: SWTOTHIRD (NA) VCTRM-HP: OOU-TPT (NA)
DS3: LOF (CR) NE-SREF: SYNCPRI (MJ) VCTRM-HP: LP-PLM (CR)
DS3: LOS (CR) NE-SREF: SYNCSEC (MN) VCTRM-HP: HP-RFI (NR)
DS3: LPBKDS3FEAC (NA) NE-SREF: SYNCTHIRD (MN) VCTRM-HP: ROLL (NA)
DS3: LPBKDS3FEAC-CMD (NA) STM: MS-AIS (NR) VCTRM-HP: ROLL-PEND (NR)
DS3: LPBKFACILITY (NA) STM: ALS (NA) VCTRM-HP: HP-DEG (NA)
DS3: LPBKTERMINAL (NA) STM: APSB (MN) VCTRM-HP: HP-EXC (NA)
DS3: RAI (NA) STM: APSCDFLTK (MN) VCTRM-HP: SQM (CR)
DS3: SD (NA) STM: APSCINCON (MN) VCTRM-HP: HP-TIM (CR)
Table 2-8 ONS 15310-MA SDH Alarm List by Logical Object as Shown in Alarm Profile (continued)
