TIC QUANTUM Operation
10/04 3-15
Adjusting the floor conveyor
speed
Pressing this button increases the floor conveyor speed of all further
runs.
Pressing this button decreases the floor conveyor speed of all further
runs.
The floor conveyor can also be reversed during loading by
simultaneously pressing both buttons. Reversing is always carried out at
speed 9.
After the floor conveyor has been reversed, the floor conveyor speed
must be increased by pressing this button.
Open / close knife frame
The floor conveyor speed is displayed at the bottom left in the control
panel display. It can be adjusted within the range from 0 to 9: 0 – 9
(standstill – fast)
Open the cutting frame by means of this button (1
st
stage). Engage the
pto to clear the blockage.
As soon as the conveyor channel is free, close the cutting frame by
pressing this key. Press this key until the display shows a totally closed
knife frame.
If the knife frame is to be completely lowered (2
nd
stage, e.g. for repairs o
r
dismounting the rotor), this key must be pressed above the cutting
trough.
Close the knife frame by pressing this key above the knife frame.
Attention!
If the knife frame is totally open, it must be closed very carefully and
slowly.
When folding up the frame, ensure that the cutting knives will not collide
with the rotor tines.
