Parameter Regulation: Pump Configuration
The following parameters can be modified:
The following tables show the different value at which the parameters can be set.
1. Acceleration Delay Acceleration ramp for lift(See Tables Below).
2. Deceleration Delay Deceleration ramp for lift(See Tables Below).
3. Acceleration Delay Tilt Acceleration ramp for tilt(See Tables Below).
4. Deceleration Delay Tilt Deceleration ramp for tilt(See Tables Below).
5. Acceleration Delay Aux1 Acceleration ramp for Aux1(See Tables Below).
6. Deceleration Delay Aux1 Deceleration ramp for Aux1(See Tables Below).
7. Acceleration Delay Aux2 Acceleration ramp for Aux2(See Tables Below).
8. Deceleration Delay Aux2 Deceleration ramp for Aux2(See Tables Below).
9. Max Speed Up:
Determine the maximum lifting speed with a Potentiometer control (See Tables Below).
10. Min Speed Up: Determine the minimum lifting speed with a potentiometer control when the lifting
enable switch is closed (See Tables Below).
11. Cutback Speed Speed when cutback switch is activated
12. 1st Speed Fine: First speed (Tilt Speed), fine adjustment (See Tables Below).
13. 2nd Speed Fine: Second speed, fine adjustment (See Tables Below).
14. 3rd Speed Fine: Third speed, fine adjustment (See Tables Below).
15. 4th Speed Fine: Fourth speed, fine adjustment.
16. Hyd Speed Fine: Hydro speed, fine adjustment.
17. Idle Speed: Set speed when steer on demand is active but pressure sensor is not moving. (Not used)
18. Idle Time: The set time delay before stopping the motor when steer demand is active and pressure
sensor is not moving. (Not used)
19. Max Current: Maximum current of the controller (See Tables Below).
20. Auxilary Time: Time delay when power steering function request is switched off (See Tables Below).
AC3
PW
(80V)
PARAMETERS
PROGRAM LEVEL
UNIT 0 1 2 3 4 5 6 7 8 9
Acceleration Delay Sec. 0.5 0.7 1 1.4 1.9 2.5 3.2 4 4.8 5.5
Deceleration Delay Sec. 0.5 0.7 1 1.4 1.9 2.5 3.2 4 4.8 5.5
Acceleration Delay Tilt Sec. 0.5 0.7 1 1.4 1.9 2.5 3.2 4 4.8 5.5
Deceleration Delay Tilt Sec. 0.5 0.7 1 1.4 1.9 2.5 3.2 4 4.8 5.5
Acceleration Delay Aux1 Sec. 0.5 0.7 1 1.4 1.9 2.5 3.2 4 4.8 5.5
Deceleration Delay Aux1 Sec. 0.5 0.7 1 1.4 1.9 2.5 3.2 4 4.8 5.5
Acceleration Delay Aux2 Sec. 0.5 0.7 1 1.4 1.9 2.5 3.2 4 4.8 5.5
Deceleration Delay Aux2 Sec. 0.5 0.7 1 1.4 1.9 2.5 3.2 4 4.8 5.5
Max Speed Up Hz 0-200
Min Speed Up Hz 0 13.5 15 16.5 18 19.5 21 22.5 24 25.5
Cutback Speed % 10 20 30 40 50 60 70 80 90 100
1st Speed Fine Hz 0-200
2nd Speed Fine Hz 0-200
3rd Speed Fine Hz 0-200
4th Speed Fine Hz 0-200
Hyd Speed Fine Hz 0-200
Idle Speed Hz 6 8 10 12 14 16 18 20 22 24
Idle Time Sec. 1 2 4 8 10 12 14 16 18 20
Max Current % IMAX 44 50 56 63 69 75 81 87 94 100
Auxilary Time Sec. 0123 4 6 8101215
