Group 32, Tilt Cylinders
32-3-4 • Tilt Cylinder Removal and Replacement SM 765, Nov ’06
N
O
TEN
O
TEN
O
TEN
O
TEN
O
TE
If the rod-end yoke has been removed from
the rod or loosened for adjustment, reinstall
the clamp bolts to a torque of 166-193 N.m
(122-142 ft-lb). Nuts must be on inside of
upright rails Orientation of the rod-end yoke
bolt hole is to be up as shown on the left side
of the illustration on the previous page.
5. Install rod-end lock-plate in slot and fasten to yoke
with fastener and washer. Tighten fastener to a torque
of 40-45 N⋅m (30-33 ft-lb).
6. Install tilt cylinder hydraulic lines. Check Group 40
for hydraulic fitting tightening procedures. O-rings
of fittings should be lightly coated with clean
hydraulic fluid or compatible oil.
7. Remove hoist chain from upright.
8. See Section 2 for tilt cylinder adjustment procedures.
When adjustments are made, check all upright com-
ponents under load before returning the truck to ser-
vice. Nuts must be on inside.
