1) Search for xc18v04.bsd in Xilinx installation directory.
2) Change Part Number from 0101000000110110 to 0101000000100110 in
the file.
3) Save the file, then close and open impact. After doing this the prom is
accessible from impact.
Example File location: C:\Xilinx\14.5\LabTools\LabTools\xc18v00\data
You can use the Firmware report tool in EHX to confirm the firmware version of
H8 application and FPGA code. The Firmware report tool does not provide
firmware version information for DSP code.
To use the Firmware report tool:
4) Open EHX and go to System > Layout.
5) Right click the matrix icon.
6) Select Firmware > Firmware report.
To upgrade the MVX FPGA with Xilinx tools:
1. Ensure that version 11.1 of the Xilinx programming tools has been installed.
Tip: For more information about installing the Xilinx programming tools, see
Appendix J:Xilinx tools.
2. Connect the USB connector of the download cable (Platform cable USB DLC9G) to
the USB port of the PC.
3. Connect the 14way IDC header to CON12 (see Figure 7-2: MVX-A16 MK I
card: J1, CON).
4. Power up the MVX-A16 card and start the iMPACT programming tool.
5. In Load Project, select Cancel.
6. In Flows, double click Boundary Scan. Right click the main window and select
Initialize Chain / Ctrl+ I:
