7. Click Next and then browse to the E-MADI64 code file (application, DSP or FPGA
code files (*.fwc)).
Tip: See Step 1 for the location of the .fwc files on the Eclipse HX v9.1 USB.
8. Click Next and confirm that the details displayed are correct.
9. Click Next and confirm that the download commences.
Note:
The E-MADI64 card status light flashes green while the upgrade is in process
(LED on to off ratio: 1:4 at 0.5Hz). When the upgrade is complete, the status
light is lit green at a steady heartbeat (LED on to off ratio: 1:1 at 1 Hz).
10. When the download has completed, click Finish to close the update firmware
wizard.
11. Ensure that the E-MADI64 cards reset once the download is complete. All the
cards are upgraded at the same time.
Table 11-4: Approximate reset times per system
12. Confirm the updated firmware version by opening EHX and going to
Matrix event log > Matrix overview.
Note:
You can also use the Firmware report tool in EHX to confirm the firmware version
for the H8 boot code (see the previous procedure), H8 application code and FPGA.
However, the Firmware report tool does not provide firmware version information
for DSP code.
To use the Firmware report tool:
b. Open EHX and go to System > Layout.
c. Right click the matrix icon.
d. Select Firmware > Firmware report.
