Eclipse | Upgrade Guide
Page 191
Observe all electrical shock hazard warning and precautions for
handling electrostatic sensitive devices
Tip: For help with selecting the other procedures you require for upgrading to EHX
V5.2.5, see the quick reference procedures tables in 2 Selecting Upgrade
Procedures.
To upgrade the AES-6 FPGA:
1. Ensure you have the following equipment:
Required equipment
Description / comments
PC with a serial port
A USB-to-serial adapter is usually acceptable.
CellCom / FreeSpeak /
FreeSpeak II (FSBP)
registration cable
PD4007Z, DB-9 to 3.5mm jack.
The appropriate AES-6
FPGA code file
The AES-6 FPGA code is available from the Drivers
USB:
Drivers USB > ECLIPSE DRIVERS >
Other_Software > xxxxxx - AES-6 FPGA
(where xxxxxx represents the product number)
Tera Term terminal
software
Third party software is available from either of
the Eclipse HX 9.0 upgrade media:
Software USB > SOFTWARE - EHX.xxx >
3rd_Party_Software > Teraterm
Drivers USB > ECLIPSE DRIVERS >
3rd_Party_Software > Teraterm
Tip: For more information about installing Tera
Term, see Appendix G: Tera Term
Table 16-3: Required equipment
2. Fit the AES-6 card to a parent unit.
3. Run TeraTerm. Configure the serial settings to the following:
