Eclipse | Upgrade Guide

Page 200

10. Confirm the updated firmware version using either:

• The local menu on the beltpack.

• The EHX firmware report tool:

- Connect the device to the matrix and allow it to connect.

- Go to EHX > System > layout.

- Right click the matrix icon.

- Select Firmware > Firmware report.
