PC with an Ethernet
connector
LAN cable for the PC-to-
Eclipse HX PiCo connection
For direct connections, use Ethernet crossover
cable. If the connection passes through an
Ethernet switch on its way to the PC / matrix,
use straight CAT5 cable.
EHX must be configured and operational.
An EHX configuration file
(*.ccn or *.hxn file format)
The configuration file must have an
appropriate IP address set.
The appropriate *.fwr data
file for the Eclipse HX-PiCo
You can find the *.fwr data file on the
software USB at:
Software USB > SOFTWARE - EHX.xxx >
SOFTWARE - EHX.xxx > Eclipse HX-PiCo
> xxxxxx – Application Code (where
xxxxxx represents the product number).
Table 6-2: Required equipment
2) Start EHX. Select File > Matrix Connection.
3) In the Matrix Connection dialog, select the Ethernet communications option.
4) Connect the PC with the Eclipse HX-PiCo, using the LAN port on the rear of the
matrix.
5) Do one of the following:
• If you are running EHX in Client-Server mode, select File > Import project.
Navigate to the configuration (*.ccn) file and click Open to import the file.
• If you are running EHX in Client-Only mode, select File > Open. Navigate to the
configuration (*.ccn) and open the file.
Note: EHX can open *.ccn format files as well as its own *.hxn format
configuration files.
6) In EHX, select System > Layout. In the work area, right click the Eclipse HX-
PiCo.
7) From the menu, select Firmware > Update Firmware.
To Next Page
