Eclipse | Upgrade Guide
Page 91
Table 6-6: Upgrading the Eclipse HX-PiCo MVX code
Note: Because of small differences in PCB layout, it may not be possible to complete the
upgrade of the MVX application code on a small number of Eclipse HX-PiCo units, using
EHX. If the upgrade fails, you can still upgrade the MVX application code using Renesas
FDT (which is suitable for all Eclipse HX-PiCo units).
6.4.1 Upgrading the Eclipse HX-PiCo MVX application code
with EHX
Note: To upgrade the Eclipse HX-PiCo MVX application code with EHX, your system must
already be running a version of Eclipse HX.
Recommendation
Clear-Com recommends that you monitor the MVX application code upgrade using the
Event Log in EHX. The upgrade process is complete when the MVXs on the Eclipse HX-
PiCo briefly disappear and then reappear in the log. To check that the upgrade has been
successful, run a firmware report.
If the upgrade is unsuccessful, use the Renesas FDT to upgrade the MVX code
(see 6.4.2 Upgrading the Eclipse HX-PiCo MVX boot and/or app code using the
Renesas FDT).
To upgrade the Eclipse HX-PiCo MVX application code using EHX:
1) Ensure that you have the following equipment:
Required equipment
Description / comments
PC with an Ethernet
connector
-
Serial cable or Ethernet
cable for the PC to matrix
connection
-
EHX installation
EHX must be configured and operational.
An EHX configuration file
(*.hxn or *.ccn format)
The configuration file must have an
appropriate IP address set.
The appropriate *.fwc
format file for the Eclipse
HX-PiCo MVX cards /
sections
You can find the Eclipse HX-PiCo MVX
application code (*.fwc) file on the software
USB:
Drivers USB > ECLIPSE DRIVERS >
ECLIPSE DRIVERS > PiCo-HX_PiCo_E-32
> xxxxxx-MVX Application
