Eclipse | Upgrade Guide
Page 94
(*.fwc format for the
separate MVX boot file,
*.mot format for the
combined MVX boot and
application code file )
Drivers USB > ECLIPSE DRIVERS > PiCo-
HX_PiCo_E-32 > xxxxxx-MVX Boot
Drivers USB > ECLIPSE DRIVERS > PiCo-
HX_PiCo_E-32 > xxxxxx-MVX Combined
Boot & App
Where xxxxxx represents the product number.
Table 6-8: Required equipment
2) Install the Renesas Flash Development Toolkit 3.4 Basic (FDT). Accept the
default install settings.
3) Start the Renesas Flash Development Toolkit 3.4 (FDT) from Programs,
selecting the basic Startup option.
4) Access the configuration (settings) dialogs, by selecting Options > New
Settings... Configure the FDT, as shown in the table below:
Settings dialog /
option
Setting to enter
Select Device
H8S/2318F
Select Port
COM1 (Change to match a COM port present on the
PC)
CPU Frequency
20.0000 Mhz
Connection
Boot mode
Recommended
Speed
38400 (Deselect the Use-Default option)
Protection
Automatic
Messaging
Advanced
User Area
Selected (Checked)
Table 6-9: FDT settings
Note:
The first time the FDT is run, the settings dialogs are displayed by default. After
the FDT has been configured, the settings dialogs are no longer shown by default.
Tip: For more information about installing and configuring the Renesas FDT, see
Appendix E: Hitachi Renesas Flash Development Tool.
5) In the Download window, click Options and ensure that:
