c. Select Program Flash from the Flash Development Toolkit (FDT) program.
d. Confirm that FDT reports the image has been written successfully.
e. Remove the serial cable.
f. Remove jumper JP10.
For the location of connectors, jumpers and reset switch positions on the Eclipse
HX-PiCo, see Figure 6-14: Eclipse HX-PiCo main board.
Note: If the MVX card fails to upgrade, press the Reset button, located
near the H8FP1 (JP11) connector and select Program Flash from
the FDT again.
If you are using a USB-to-serial adaptor, the adaptor may have to be unplugged and re-
plugged to enable the upgrade to start on some computers. If you are running the EHX
