User Guide| FreeSpeak II for Eclipse HX
Key to beltpack bottom connectors
Feature Description
LED torch
LED torch control
Headset socket (4-pin XLR–M)
Pin Function
1 Mic ground
2 Mic +
3 Earphone ground
4 Earphone
Headset socket pin out
Headset socket (7-pin XLR–M)
Pin Function
1 Mic ground
2 Mic +
3 Ground
4 Left Headphone Output
5 Right Headphone Output
6 PTT1
7 PTT2/Headset detect
Headset socket pin out
3.5 mm stereo jack.
Micro USB connector.
Page 28
