User Guide| FreeSpeak II for Eclipse HX
Key to beltpack front controls
Feature Description
A
Right rotary level control. Turn clockwise or counter-clockwise to adjust volume.In
menu mode, turn clockwise or counter-clockwise to navigate the menus.
B
Power button. Press to power up or power down the beltpack.
C
Reply key. Reply key can be configured as an extra fifth channel using the
Configuration Editor or EHX software.
D
Mnu key. Press firmly for about two seconds to enter menu mode To exit menu mode,
press the menu key again. If you tap the Menu key, the Listen Again feature is
activated. See Setting the listen again option on page 44.
E
Left rotary level control. Turn clockwise or counter-clockwise to adjust volume.In menu
mode, turn clockwise or counter-clockwise to navigate the menus.
4.2.5 Beltpack bottom connectors
