Page 23 399G169 Rev B 27 April 2016
3.1.2 Antenna coverage (how far?)
Antennas provide circular (omnidirectional) coverage.
In ideal conditions, an antenna range can go up to 500 meters (1640 feet).
However, an average range, taking into account objects and conditions that
impede radio waves, is between 50 - 150 meters (164 - 490 feet).
3.1.3 Possible distance from Base Station to antenna
The Base Station can power 1 antenna to a distance of 300 meters (984
feet). More than one antenna and/or greater distances will need direct power
supplied to the antenna.
The figures in this table are based
on the use of 24AWG Cat5/6
Capacity (distance and no. of
devices)
Base to antenna. No PSU at antenna.
1 antenna only.
300 meters (984 feet).
