CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
750-426 107
AB[12]15 BI 208 DI 208 10208 nvoAB_12_15_XXX SNVT_switch
Air Actuator 2 Position Deviation BI 209 DI 209 10209 nvoArAc2PsDv_XXX SNVT_switch
Air Actuator 2 Feedback Low BI 210 DI 210 10210 nvoArAc2FBLo_XXX SNVT_switch
Air Actuator 2 Feedback High BI 211 DI 211 10211 nvoArAc2FBHi_XXX SNVT_switch
Air Actuator 2 Modbus Comm Error (Node 4) BI 212 DI 212 10212 nvoArA2MdCmE_XXX SNVT_switch
Air Actuator 2 Manual PB Pressed BI 213 DI 213 10213 nvoArA2MnPBP_XXX SNVT_switch
Air Actuator 2 Fault BI 214 DI 214 10214 nvoAirAct2Fl_XXX SNVT_switch
Air Actuator 2 Not At Purge BI 215 DI 215 10215 nvoArAc2NoPr_XXX SNVT_switch
Air Actuator 2 Not At Lightoff BI 216 DI 216 10216 nvoArAc2NoLt_XXX SNVT_switch
Air Actuator Not At Lightoff BI 217 DI 217 10217 nvoArAcNotLt_XXX SNVT_switch
Fuel Actuator 1 Not At Lightoff BI 218 DI 218 10218 nvoFlA1NoLt_XXX SNVT_switch
Fuel Actuator 2 Not At Lightoff BI 219 DI 219 10219 nvoFlA2NoLt_XXX SNVT_switch
FGR Actuator Not At Lightoff BI 220 DI 220 10220 nvoFGRAcNoLt_XXX SNVT_switch
VFD Not At Lightoff BI 221 DI 221 10221 nvoVFDNoLt_XXX SNVT_switch
AB[13]13 BI 222 DI 222 10222 nvoAB_13_13_XXX SNVT_switch
AB[13]14 BI 223 DI 223 10223 nvoAB_13_14_XXX SNVT_switch
AB[13]15 BI 224 DI 224 10224 nvoAB_13_15_XXX SNVT_switch
AB[14]0 BI 225 DI 225 10225 nvoAB_14_0_XXX SNVT_switch
AB[14]1 BI 226 DI 226 10226 nvoAB_14_1_XXX SNVT_switch
AB[14]2 BI 227 DI 227 10227 nvoAB_14_2_XXX SNVT_switch
AB[14]3 BI 228 DI 228 10228 nvoAB_14_3_XXX SNVT_switch
AB[14]4 BI 229 DI 229 10229 nvoAB_14_4_XXX SNVT_switch
AB[14]5 BI 230 DI 230 10230 nvoAB_14_5_XXX SNVT_switch
AB[14]6 BI 231 DI 231 10231 nvoAB_14_6_XXX SNVT_switch
AB[14]7 BI 232 DI 232 10232 nvoAB_14_7_XXX SNVT_switch
AB[14]8 BI 233 DI 233 10233 nvoAB_14_8_XXX SNVT_switch
AB[14]9 BI 234 DI 234 10234 nvoAB_14_9_XXX SNVT_switch
AB[14]10 BI 235 DI 235 10235 nvoAB_14_10_XXX SNVT_switch
AB[14]11 BI 236 DI 236 10236 nvoAB_14_11_XXX SNVT_switch
AB[14]12 BI 237 DI 237 10237 nvoAB_14_12_XXX SNVT_switch
AB[14]13 BI 238 DI 238 10238 nvoAB_14_13_XXX SNVT_switch
AB[14]14 BI 239 DI 239 10239 nvoAB_14_14_XXX SNVT_switch
AB[14]15 BI 240 DI 240 10240 nvoAB_14_15_XXX SNVT_switch
Flame Strength Honeywell AI 1 AI 1 30001 nvoFlmStrHny_XXX SNVT_count_f
Combustion Air Fan Speed AI 2 AI 2 30003 nvoCmArFnSpd_XXX SNVT_count_f
AR[2] AI 3 AI 3 30005 nvoArFnVFDMt_XXX SNVT_count_f
Boiler Efficiency AI 4 AI 4 30007 nvoBlrEff_XXX SNVT_lev_percent
Firing Rate AI 5 AI 5 30009 nvoFirRat_XXX SNVT_lev_percent
O2 Level AI 6 AI 6 30011 nvoO2Lvl_XXX SNVT_lev_percent
SP Steam Pressure/Water Temp AI 7 AI 7 30013 nvoSPStPWtTp_XXX SNVT_count_f
Water Level AI 8 AI 8 30015 nvoWtrLvl_XXX SNVT_press_f
Steam Pressure or Hot Water Temp AI 9 AI 9 30017 nvoStPrHWTmp_XXX SNVT_count_f
AR[9] AI 10 AI 10 30019 nvoAR_9_XXX SNVT_count_f
Stack Temp Before Economizer AI 11 AI 11 30021 nvoStkTpBfEc_XXX SNVT_temp_p
Combustion Air Temp AI 12 AI 12 30023 nvoComAirTmp_XXX SNVT_temp_p
Water Temp Shell/Outdoor Temp AI 13 AI 13 30025 nvoWtTpShl_XXX SNVT_temp_p
Feedwater Temp/Econ Water Out Temp AI 14 AI 14 30027 nvoFdWtTp_XXX SNVT_temp_p
Stack Temp After Econ/Return HW AI 15 AI 15 30029 nvoStkTmpEco_XXX SNVT_temp_p
Economizer Water In Temp AI 16 AI 16 30031 nvoEcWtInTmp_XXX SNVT_temp_p
AI Slot8Ch0 Value/2Stg Econ Temp IN AI 17 AI 17 30033 nvoAISlCh0Vl_XXX SNVT_count_f
AI Slot8Ch1 Value/2Stg Econ Temp OUT AI 18 AI 18 30035 nvoAISlCh1Vl_XXX SNVT_count_f
AI Slot8 Ch2 Value (EU) AI 19 AI 19 30037 nvoAISlCh2Vl_XXX SNVT_count_f
AI Slot8 Ch3 Value (EU) AI 20 AI 20 30039 nvoAISlCh3Vl_XXX SNVT_count_f
Safety Valve Setting or Max Water Temp AI 21 AI 21 30041 nvoSftVlvSet_XXX SNVT_count_f
Header Pressure or Temp 2 Boiler LL AI 22 AI 22 30043 nvoHdPrTpBLL_XXX SNVT_count_f
SP 2 Boiler LL AI 23 AI 23 30045 nvoSP2BlrLL_XXX SNVT_count_f
Boiler Off Point AI 24 AI 24 30047 nvoBlrOffPt_XXX SNVT_count_f
Boiler On Point AI 25 AI 25 30049 nvoBlrOnPt_XXX SNVT_count_f
Condensate Return Valve Output Command AI 26 AI 26 30051 nvoCdRtVOtCm_XXX SNVT_lev_percent
Makeup Bypass Valve Output Command AI 27 AI 27 30053 nvoMkByVOtCm_XXX SNVT_lev_percent
Slot8 Ch0 FLo Total AI 28 AI 28 30055 nvoSlC0FlTo_XXX SNVT_count_f
Slot8 Ch1 FLo Total AI 29 AI 29 30057 nvoSlC1FlTo_XXX SNVT_count_f
Slot8 Ch2 FLo Total AI 30 AI 30 30059 nvoSlC2FlTo_XXX SNVT_count_f
Slot8 Ch3 FLo Total AI 31 AI 31 30061 nvoSlC3FlTo_XXX SNVT_count_f
Slot8 Ch4 Flo Total AI 32 AI 32 30063 nvoSlC4FlTo_XXX SNVT_count_f
Slot8 Ch5 Flo Total AI 33 AI 33 30065 nvoSlC5FlTo_XXX SNVT_count_f
HAWK_4000_V2 Modbus RTU Mappings to BACnet, Metasys N2 and LonWorks (Continued)
Point Name BACnet
Object
Type
BACnet
Object ID
N2
Data
Type
N2 Point
Address
Modbus
Register
LonWorks Name LonWorks SNVT
