ProtoNode Gateway
108 750-426
Slot8 Ch6 Flo Total AI 34 AI 34 30067 nvoSlC6FlTo_XXX SNVT_count_f
Slot8 Ch7 Flo Total AI 35 AI 35 30069 nvoSlC7FlTo_XXX SNVT_count_f
Slot8 Ch4 EU AI 36 AI 36 30071 nvoSlC4_EU_XXX SNVT_count_f
Slot8 Ch5 EU AI 37 AI 37 30073 nvoSlC5_EU_XXX SNVT_count_f
Slot8 Ch6 EU AI 38 AI 38 30075 nvoSlC6_EU_XXX SNVT_count_f
Slot8 Ch7 EU AI 39 AI 39 30077 nvoSlC7_EU_XXX SNVT_count_f
Stack Pressure AI 40 AI 40 30079 nvoStkPrs_XXX SNVT_count_f
AR[40] AI 41 AI 41 30081 nvoAR_40_XXX SNVT_count_f
AR[41] AI 42 AI 42 30083 nvoAR_41_XXX SNVT_count_f
AR[42] AI 43 AI 43 30085 nvoAR_42_XXX SNVT_count_f
AR[43] AI 44 AI 44 30087 nvoAR_43_XXX SNVT_count_f
AR[44] AI 45 AI 45 30089 nvoAR_44_XXX SNVT_count_f
AR[45] AI 46 AI 46 30091 nvoAR_45_XXX SNVT_count_f
AR[46] AI 47 AI 47 30093 nvoAR_46_XXX SNVT_count_f
AR[47] AI 48 AI 48 30095 nvoAR_47_XXX SNVT_count_f
AR[48] AI 49 AI 49 30097 nvoAR_48_XXX SNVT_count_f
AR[49] AI 50 AI 50 30099 nvoAR_49_XXX SNVT_count_f
Burner Control Status Line 1 Honeywell AI 52 AI 52 30102 nvoBSt1Hnywl_XXX SNVT_count_f
Burner Control Status Line 2 Honeywell AI 53 AI 53 30103 nvoBSt2Hnywl_XXX SNVT_count_f
Burner Control Status Line 1 Fireye AI 54 AI 54 30104 nvoBSt1Freye_XXX SNVT_count_f
Burner Control Status Line 2 Fireye AI 55 AI 55 30105 nvoBSt2Freye_XXX SNVT_count_f
Flame Signal Fireye AI 56 AI 56 30106 nvoFlSgFrey_XXX SNVT_count_f
Fuel 1Type AI 57 AI 57 30107 nvoFl1Type_XXX SNVT_count_f
Fuel 2 Type AI 58 AI 58 30108 nvoFl2Type_XXX SNVT_count_f
Fuel 3 Type AI 59 AI 59 30109 nvoFl3Type_XXX SNVT_count_f
Elapsed Time (First 16 Bits) AI 61 AI 61 30111 nvoElpTm1_XXX SNVT_time_hour
Elapsed Time (Second 16 Bits) AI 62 AI 62 30112 nvoElpTm2_XXX SNVT_time_hour
Number Of Cycles (First 16 Bits) AI 63 AI 63 30113 nvoNumCyc1_XXX SNVT_count_f
Number Of Cycles (Second 16 Bits) AI 64 AI 64 30114 nvoNumCyc2_XXX SNVT_count_f
AI[13] AI 65 AI 65 30115 nvoAI_13_XXX SNVT_count_f
AI[14] AI 66 AI 66 30116 nvoAI_14_XXX SNVT_count_f
AI[15] AI 67 AI 67 30117 nvoAI_15_XXX SNVT_count_f
AI[16] AI 68 AI 68 30118 nvoAI_16_XXX SNVT_count_f
AI[17] AI 69 AI 69 30119 nvoAI_17_XXX SNVT_count_f
AI[18] AI 70 AI 70 30120 nvoAI_18_XXX SNVT_count_f
AI[19] AI 71 AI 71 30121 nvoAI_19_XXX SNVT_count_f
AI[20] AI 72 AI 72 30122 nvoAI_20_XXX SNVT_count_f
AI[21] AI 73 AI 73 30123 nvoAI_21_XXX SNVT_count_f
AI[22] AI 74 AI 74 30124 nvoAI_22_XXX SNVT_count_f
AI[23] AI 75 AI 75 30125 nvoAI_23_XXX SNVT_count_f
AI[24] AI 76 AI 76 30126 nvoAI_24_XXX SNVT_count_f
AI[25] AI 77 AI 77 30127 nvoAI_25_XXX SNVT_count_f
AI[26] AI 78 AI 78 30128 nvoAI_26_XXX SNVT_count_f
AI[27] AI 79 AI 79 30129 nvoAI_27_XXX SNVT_count_f
AI[28] AI 80 AI 80 30130 nvoAI_28_XXX SNVT_count_f
AI[29] AI 81 AI 81 30131 nvoAI_29_XXX SNVT_count_f
Elapsed Time AI 82 AI 82 30132 nvoElapTim_XXX SNVT_time_hour
Number Of Cycles AI 83 AI 83 30134 nvoNumCyc_XXX SNVT_count_f
AB[0] AI 201 AI 201 30201 nvoAB_0_XXX SNVT_count_f
AB[1] AI 202 AI 202 30202 nvoAB_1_XXX SNVT_count_f
AB[2] AI 203 AI 203 30203 nvoAB_2_XXX SNVT_count_f
AB[3] AI 204 AI 204 30204 nvoAB_3_XXX SNVT_count_f
AB[4] AI 205 AI 205 30205 nvoAB_4_XXX SNVT_count_f
AB[5] AI 206 AI 206 30206 nvoAB_5_XXX SNVT_count_f
AB[6] AI 207 AI 207 30207 nvoAB_6_XXX SNVT_count_f
AB[7] AI 208 AI 208 30208 nvoAB_7_XXX SNVT_count_f
AB[8] AI 209 AI 209 30209 nvoAB_8_XXX SNVT_count_f
AB[9] AI 210 AI 210 30210 nvoAB_9_XXX SNVT_count_f
AB[10] AI 211 AI 211 30211 nvoAB_10_XXX SNVT_count_f
AB[11] AI 212 AI 212 30212 nvoAB_11_XXX SNVT_count_f
AB[12] AI 213 AI 213 30213 nvoAB_12_XXX SNVT_count_f
AB[13] AI 214 AI 214 30214 nvoAB_13_XXX SNVT_count_f
AB[14] AI 215 AI 215 30215 nvoAB_14_XXX SNVT_count_f
Heart Beat From BMS BV 1 DO 1 00001 nvoHtBtFrBMS_XXX SNVT_switch
Rem Start From BMS BV 2 DO 2 00002 nvoRmStFrBMS_XXX SNVT_switch
AWB[0]2 BV 3 DO 3 00003 nvoAWB_0_2_XXX SNVT_switch
HAWK_4000_V2 Modbus RTU Mappings to BACnet, Metasys N2 and LonWorks (Continued)
Point
Name BACnet
Object
Type
BACnet
Object ID
N2
Data
Type
N2 Point
Address
Modbus
Register
LonWorks Name LonWorks SNVT
To Next Page
