ProtoNode Gateway
750-426 121
Alarm Warn Annunciate BI 259 BD 3 10259 nvoAlmWrnAnn_XXX SNVT_switch
Alarm Trip Annunciate BI 260 BD 4 10260 nvoAlmTrpAnn_XXX SNVT_switch
Water Level Low BI 261 BD 5 10261 nvoWtrLvlLo_XXX SNVT_switch
Water Level High BI 262 BD 6 10262 nvoWtrLvlHi_XXX SNVT_switch
High O2 Shutdown BI 263 BD 7 10263 nvoHiO2Shtdn_XXX SNVT_switch
High Air/Fuel Deviation (Full Metered) BI 264 BD 8 10264 nvoHiArFlDev_XXX SNVT_switch
High FGR Flow Deviation (Full Metered) BI 265 BD 9 10265 nvoHiFGRFlDv_XXX SNVT_switch
High-High FGR Flow Deviation (Full Metrd) BI 266 BD 10 10266 nvoHHFGRFlDv_XXX SNVT_switch
Flow Bad Quality (Full Metered) BI 267 BD 11 10267 nvoFlwBdQual_XXX SNVT_switch
Trip (Full Metered) BI 268 BD 12 10268 nvoTrip_XXX SNVT_switch
AB[16]12 BI 269 BD 13 10269 nvoAB_16_12_XXX SNVT_switch
AB[16]13 BI 270 BD 14 10270 nvoAB_16_13_XXX SNVT_switch
AB[16]14 BI 271 BD 15 10271 nvoAB_16_14_XXX SNVT_switch
AB[16]15 BI 272 BD 16 10272 nvoAB_16_15_XXX SNVT_switch
Flame Strength Honeywell AI 1 AI 1 30001 nvoFlmStrHny_XXX SNVT_count_f
Combustion Air Fan Speed (Hz) AI 2 AI 2 30003 nvoCmArFnSpd_XXX SNVT_count_f
Air Fan VFD Motor KW AI 3 AI 3 30005 nvoArFnVFDMt_XXX SNVT_count_f
Boiler Efficiency AI 4 AI 4 30007 nvoBlrEff_XXX SNVT_lev_percent
Firing Rate AI 5 AI 5 30009 nvoFirRat_XXX SNVT_lev_percent
O2 Level AI 6 AI 6 30011 nvoO2Lvl_XXX SNVT_lev_percent
SP Steam Pressure/Water Temp AI 7 AI 7 30013 nvoSPStPWtTp_XXX SNVT_count_f
Water Level AI 8 AI 8 30015 nvoWtrLvl_XXX SNVT_press_f
Steam Pressure or Hot Water Temp AI 9 AI 9 30017 nvoStPrHWTmp_XXX SNVT_count_f
AR[9] AI 10 AI 10 30019 nvoAR_9_XXX SNVT_count_f
Stack Temp Before Economizer AI 11 AI 11 30021 nvoStkTpBfEc_XXX SNVT_temp_p
Combustion Air Temp AI 12 AI 12 30023 nvoComAirTmp_XXX SNVT_temp_p
Water Temp Shell/Outdoor Temp AI 13 AI 13 30025 nvoWtTpShl_XXX SNVT_temp_p
Feedwater Temp/Econ Water Out Temp AI 14 AI 14 30027 nvoFdWtTp_XXX SNVT_temp_p
Stack Temp After Econ/Return HW AI 15 AI 15 30029 nvoStkTmpEco_XXX SNVT_temp_p
Economizer Water In Temp AI 16 AI 16 30031 nvoEcWtInTmp_XXX SNVT_temp_p
AI Slot8Ch0 Value/2Stg Econ Temp IN AI 17 AI 17 30033 nvoAISlCh0Vl_XXX SNVT_count_f
AI Slot8Ch1 Value/2Stg Econ Temp OUT AI 18 AI 18 30035 nvoAISlCh1Vl_XXX SNVT_count_f
AI Slot8 Ch2 Value (EU) AI 19 AI 19 30037 nvoAISlCh2Vl_XXX SNVT_count_f
AI Slot8 Ch3 Value (EU) AI 20 AI 20 30039 nvoAISlCh3Vl_XXX SNVT_count_f
Safety Valve Setting or Max Water Temp AI 21 AI 21 30041 nvoSftVlvSet_XXX SNVT_count_f
Header Pressure or Temp 2 Boiler LL AI 22 AI 22 30043 nvoHdPrTpBLL_XXX SNVT_count_f
SP 2 Boiler LL AI 23 AI 23 30045 nvoSP2BlrLL_XXX SNVT_count_f
Boiler Off Point AI 24 AI 24 30047 nvoBlrOffPt_XXX SNVT_count_f
Boiler On Point AI 25 AI 25 30049 nvoBlrOnPt_XXX SNVT_count_f
Condensate Return Valve Output Command AI 26 AI 26 30051 nvoCdRtVOtCm_XXX SNVT_lev_percent
Makeup Bypass Valve Output Command AI 27 AI 27 30053 nvoMkByVOtCm_XXX SNVT_lev_percent
Slot8 Ch0 Flo Total AI 28 AI 28 30055 nvoSl8C0FlTo_XXX SNVT_count_f
Slot8 Ch1 Flo Total AI 29 AI 29 30057 nvoSl8C1FlTo_XXX SNVT_count_f
Slot8 Ch2 Flo Total AI 30 AI 30 30059 nvoSl8C2FlTo_XXX SNVT_count_f
Slot8 Ch3 Flo Total AI 31 AI 31 30061 nvoSl8C3FlTo_XXX SNVT_count_f
Slot8 Ch4 FloTotal AI 32 AI 32 30063 nvoSl8C4FlTo_XXX SNVT_count_f
Slot8 Ch5 Flo Total AI 33 AI 33 30065 nvoSl8C5FlTo_XXX SNVT_count_f
Slot8 Ch6 Flo Total AI 34 AI 34 30067 nvoSl8C6FlTo_XXX SNVT_count_f
Slot8 Ch7 Flo Total AI 35 AI 35 30069 nvoSl8C7FlTo_XXX SNVT_count_f
Slot8 Ch4 EU AI 36 AI 36 30071 nvoSl8Ch4EU_XXX SNVT_count_f
Slot8 Ch5 EU AI 37 AI 37 30073 nvoSl8Ch5EU_XXX SNVT_count_f
Slot8 Ch6 EU AI 38 AI 38 30075 nvoSl8Ch6EU_XXX SNVT_count_f
Hawk 4500 EtherNet/IP Mappings to BACnet, Metasys N2 and LonWorks
Point
Name BACnet
Object
Type
BACnet
Object ID
N2
Data
Type
N2 Point
Address
Modbus
Register
LonWorks Name LonWorks SNVT
