ProtoNode Gateway
750-426 122
Slot8 Ch7 EU AI 39 AI 39 30077 nvoSl8Ch7EU_XXX SNVT_count_f
Stack Pressure AI 40 AI 40 30079 nvoStkPrs_XXX SNVT_count_f
AR[40] AI 41 AI 41 30081 nvoAR_40_XXX SNVT_count_f
Remote Setpoint AI 42 AI 42 30083 nvoRemSP_XXX SNVT_count_f
Remote Firing Rate AI 43 AI 43 30085 nvoRemFirRt_XXX SNVT_count_f
Slot 10 Ch 0 (Air Flow) EU AI 44 AI 44 30087 nvoS10C0AFlE_XXX SNVT_count_f
Slot 10 Ch 1 (Fuel 1 Flow) EU AI 45 AI 45 30089 nvoS10C1F1FE_XXX SNVT_count_f
Slot 10 Ch 2 (Fuel 2 Flow) EU AI 46 AI 46 30091 nvoS10C2F2FE_XXX SNVT_count_f
Slot 10 Ch 3 (FGR Flow) EU AI 47 AI 47 30093 nvoS10C3FGRE_XXX SNVT_count_f
Slot 10 Ch 4 (Nat Gas Temp) EU AI 48 AI 48 30095 nvoS10C4NtGE_XXX SNVT_count_f
Slot 10 Ch 5 EU AI 49 AI 49 30097 nvoS10C5EU_XXX SNVT_count_f
Slot 10 Ch 6 EU AI 50 AI 50 30099 nvoS10C6EU_XXX SNVT_count_f
Slot 10 Ch 7 EU AI 51 AI 51 30101 nvoS10C7EU_XXX SNVT_count_f
Slot 10 Ch 0 (Air Flow) Flow Total AI 52 AI 52 30103 nvoS10C0AFlF_XXX SNVT_count_f
Slot 10 Ch 1 (Fuel 1 Flow) Flow Total AI 53 AI 53 30105 nvoS10C1F1FF_XXX SNVT_count_f
Slot 10 Ch 2 (Fuel 2 Flow) Flow Total AI 54 AI 54 30107 nvoS10C2F2FF_XXX SNVT_count_f
Slot 10 Ch 3 (FGR Flow) Flow Total AI 55 AI 55 30109 nvoS10C3FGRF_XXX SNVT_count_f
Slot 10 Ch 4 (Nat Gas Temp) Flow Total AI 56 AI 56 30111 nvoS10C4NtGF_XXX SNVT_count_f
Slot 10 Ch 5 Flow Total AI 57 AI 57 30113 nvoS10C5FlTo_XXX SNVT_count_f
Slot 10 Ch 6 Flow Total AI 58 AI 58 30115 nvoS10C6FlTo_XXX SNVT_count_f
Slot 10 Ch 7 Flow Total AI 59 AI 59 30117 nvoS10C7FlTo_XXX SNVT_count_f
AR[59] AI 60 AI 60 30119 nvoAR_59_XXX SNVT_count_f
Burner Control Status Line 1 Honeywell AI 61 AI 61 30122 nvoBSt1Hnywl_XXX SNVT_count_f
Burner Control Status Line 2 Honeywell AI 62 AI 62 30123 nvoBSt2Hnywl_XXX SNVT_count_f
Burner Control Status Line 1 Fireye AI 63 AI 63 30124 nvoBSt1Freye_XXX SNVT_count_f
Burner Control Status Line 2 Fireye AI 64 AI 64 30125 nvoBSt2Freye_XXX SNVT_count_f
Flame Signal Fireye AI 65 AI 65 30126 nvoFlSgFrey_XXX SNVT_count_f
Fuel 1Type AI 66 AI 66 30127 nvoFl1Type_XXX SNVT_count_f
Fuel 2 Type AI 67 AI 67 30128 nvoFl2Type_XXX SNVT_count_f
Fuel 3 Type AI 68 AI 68 30129 nvoFl3Type_XXX SNVT_count_f
Elapsed Time (First 16 Bits) AI 69 AI 69 30130 nvoElpTm1_XXX SNVT_time_hour
Elapsed Time (Second 16 Bits) AI 70 AI 70 30131 nvoElpTm2_XXX SNVT_time_hour
Number Of Cycles (First 16 Bits) AI 71 AI 71 30132 nvoNumCyc1_XXX SNVT_count_f
Number Of Cycles (Second 16 Bits) AI 72 AI 72 30133 nvoNumCyc2_XXX SNVT_count_f
AI[13] AI 73 AI 73 30134 nvoAI_13_XXX SNVT_count_f
AI[14] AI 74 AI 74 30135 nvoAI_14_XXX SNVT_count_f
AI[15] AI 75 AI 75 30136 nvoAI_15_XXX SNVT_count_f
AI[16] AI 76 AI 76 30137 nvoAI_16_XXX SNVT_count_f
AI[17] AI 77 AI 77 30138 nvoAI_17_XXX SNVT_count_f
AI[18] AI 78 AI 78 30139 nvoAI_18_XXX SNVT_count_f
AI[19] AI 79 AI 79 30140 nvoAI_19_XXX SNVT_count_f
AI[20] AI 80 AI 80 30141 nvoAI_20_XXX SNVT_count_f
AI[21] AI 81 AI 81 30142 nvoAI_21_XXX SNVT_count_f
AI[22] AI 82 AI 82 30143 nvoAI_22_XXX SNVT_count_f
AI[23] AI 83 AI 83 30144 nvoAI_23_XXX SNVT_count_f
AI[24] AI 84 AI 84 30145 nvoAI_24_XXX SNVT_count_f
AI[25] AI 85 AI 85 30146 nvoAI_25_XXX SNVT_count_f
AI[26] AI 86 AI 86 30147 nvoAI_26_XXX SNVT_count_f
AI[27] AI 87 AI 87 30148 nvoAI_27_XXX SNVT_count_f
AI[28] AI 88 AI 88 30149 nvoAI_28_XXX SNVT_count_f
AI[29] AI 89 AI 89 30150 nvoAI_29_XXX SNVT_count_f
Elapsed Time AI 90 AI 90 30152 nvoElapTim_XXX SNVT_time_hour
Hawk 4500 EtherNet/IP Mappings to BACnet, Metasys N2 and LonWorks
Point
Name BACnet
Object
Type
BACnet
Object ID
N2
Data
Type
N2 Point
Address
Modbus
Register
LonWorks Name LonWorks SNVT
