CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
750-426 123
Number Of Cycles AI 91 AI 91 30154 nvoNumCyc_XXX SNVT_count_f
AB[0] AI 201 AI 201 30201 nvoAB_0_XXX SNVT_count_f
AB[1] AI 202 AI 202 30202 nvoAB_1_XXX SNVT_count_f
AB[2] AI 203 AI 203 30203 nvoAB_2_XXX SNVT_count_f
AB[3] AI 204 AI 204 30204 nvoAB_3_XXX SNVT_count_f
AB[4] AI 205 AI 205 30205 nvoAB_4_XXX SNVT_count_f
AB[5] AI 206 AI 206 30206 nvoAB_5_XXX SNVT_count_f
AB[6] AI 207 AI 207 30207 nvoAB_6_XXX SNVT_count_f
AB[7] AI 208 AI 208 30208 nvoAB_7_XXX SNVT_count_f
AB[8] AI 209 AI 209 30209 nvoAB_8_XXX SNVT_count_f
AB[9] AI 210 AI 210 30210 nvoAB_9_XXX SNVT_count_f
AB[10] AI 211 AI 211 30211 nvoAB_10_XXX SNVT_count_f
AB[11] AI 212 AI 212 30212 nvoAB_11_XXX SNVT_count_f
AB[12] AI 213 AI 213 30213 nvoAB_12_XXX SNVT_count_f
AB[13] AI 214 AI 214 30214 nvoAB_13_XXX SNVT_count_f
AB[14] AI 215 AI 215 30215 nvoAB_14_XXX SNVT_count_f
* Heart Beat From BMS BV 1 DO 1 00001 nvoHtBtFrBMS_XXX SNVT_switch
* Rem Start From BMS BV 2 DO 2 00002 nvoRmStFrBMS_XXX SNVT_switch
* AWB[0]2 BV 3 DO 3 00003 nvoAWB_0_2_XXX SNVT_switch
* AWB[0]3 BV 4 DO 4 00004 nvoAWB_0_3_XXX SNVT_switch
* AWB[0]4 BV 5 DO 5 00005 nvoAWB_0_4_XXX SNVT_switch
* AWB[0]5 BV 6 DO 6 00006 nvoAWB_0_5_XXX SNVT_switch
* AWB[0]6 BV 7 DO 7 00007 nvoAWB_0_6_XXX SNVT_switch
* AWB[0]7 BV 8 DO 8 00008 nvoAWB_0_7_XXX SNVT_switch
* AWB[0]8 BV 9 DO 9 00009 nvoAWB_0_8_XXX SNVT_switch
* AWB[0]9 BV 10 DO 10 00010 nvoAWB_0_9_XXX SNVT_switch
* AWB[0]10 BV 11 DO 11 00011 nvoAWB_0_10_XXX SNVT_switch
* AWB[0]11 BV 12 DO 12 00012 nvoAWB_0_11_XXX SNVT_switch
* AWB[0]12 BV 13 DO 13 00013 nvoAWB_0_12_XXX SNVT_switch
* AWB[0]13 BV 14 DO 14 00014 nvoAWB_0_13_XXX SNVT_switch
* AWB[0]14 BV 15 DO 15 00015 nvoAWB_0_14_XXX SNVT_switch
* AWB[0]15 BV 16 DO 16 00016 nvoAWB_0_15_XXX SNVT_switch
* AWB[1]0 BV 17 DO 17 00017 nvoAWB_1_0_XXX SNVT_switch
* AWB[1]1 BV 18 DO 18 00018 nvoAWB_1_1_XXX SNVT_switch
* AWB[1]2 BV 19 DO 19 00019 nvoAWB_1_2_XXX SNVT_switch
* AWB[1]3 BV 20 DO 20 00020 nvoAWB_1_3_XXX SNVT_switch
* AWB[1]4 BV 21 DO 21 00021 nvoAWB_1_4_XXX SNVT_switch
* AWB[1]5 BV 22 DO 22 00022 nvoAWB_1_5_XXX SNVT_switch
* AWB[1]6 BV 23 DO 23 00023 nvoAWB_1_6_XXX SNVT_switch
* AWB[1]7 BV 24 DO 24 00024 nvoAWB_1_7_XXX SNVT_switch
* AWB[1]8 BV 25 DO 25 00025 nvoAWB_1_8_XXX SNVT_switch
* AWB[1]9 BV 26 DO 26 00026 nvoAWB_1_9_XXX SNVT_switch
* AWB[1]10 BV 27 DO 27 00027 nvoAWB_1_10_XXX SNVT_switch
* AWB[1]11 BV 28 DO 28 00028 nvoAWB_1_11_XXX SNVT_switch
* AWB[1]12 BV 29 DO 29 00029 nvoAWB_1_12_XXX SNVT_switch
* AWB[1]13 BV 30 DO 30 00030 nvoAWB_1_13_XXX SNVT_switch
* AWB[1]14 BV 31 DO 31 00031 nvoAWB_1_14_XXX SNVT_switch
* AWB[1]15 BV 32 DO 32 00032 nvoAWB_1_15_XXX SNVT_switch
* Rem Op SP Boiler AV 1 AO 1 40001 nvoRmOpSPBlr_XXX SNVT_count_f
* Rem Firing Rate AV 2 AO 2 40003 nvoRemFirRat_XXX SNVT_lev_percent
* Rem Op SP 2 boiler Lead/Lag AV 3 AO 3 40005 nvoRmOSP2BLL_XXX SNVT_count_f
* AWR[3] AV 4 AO 4 40007 nvoAWR_3_XXX SNVT_count_f
Hawk 4500 EtherNet/IP Mappings to BACnet, Metasys N2 and LonWorks
Point Name BACnet
Object
Type
BACnet
Object ID
N2
Data
Type
N2 Point
Address
Modbus
Register
LonWorks Name LonWorks SNVT
