CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
58 750-426
NC Boiler J Outlet Temp AI 200 AI 200 30220 HSC_AI_XXX[199] nvoNCBlJOtTp_XXX SNVT_temp_p
Rem System Pump Module Input Word AI 201 AI 201 30221 HSC_AI_XXX[200] nvoRmSyPpInp_XXX SNVT_count_inc_f
Rem System Pump Module Output Word AI 202 AI 202 30222 HSC_AI_XXX[201] nvoRmSyPpOut_XXX SNVT_count_inc_f
Number of Remote System Pumps AI 203 AI 203 30223 HSC_AI_XXX[202] nvoNumSysPmp_XXX SNVT_count_inc_f
Pump Module Analog In 1 Scaled Value AI 247 AI 247 30224 HSC_AI_XXX[203] nvoPumpModA1_XXX SNVT_count_inc_f
Pump Module Analog In 2 Scaled Value AI 248 AI 248 30226 HSC_AI_XXX[204] nvoPumpModA2_XXX SNVT_count_inc_f
System Pump Speed Requested AI 249 AI 249 30228 HSC_AI_XXX[205] nvoSyPmpSpRq_XXX SNVT_count_inc_f
Pump PID Process Variable AI 250 AI 250 30230 HSC_AI_XXX[206] nvoPpPIDPrVr_XXX SNVT_count_inc_f
Pump PID Setpoint AI 251 AI 251 30232 HSC_AI_XXX[207] nvoPumpPIDSP_XXX SNVT_count_inc_f
Rem System Pump Lead Pump Number AI 204 AI 204 30234 HSC_AI_XXX[208] nvoRmPpLdNum_XXX SNVT_count_inc_f
Rem System Pump Lag1 Pump Number AI 205 AI 205 30235 HSC_AI_XXX[209] nvoRmPpLg1Nm_XXX SNVT_count_inc_f
Rem System Pump Lag2 Pump Number AI 206 AI 206 30236 HSC_AI_XXX[210] nvoRmPpLg2Nm_XXX SNVT_count_inc_f
Rem System Pump Lag3 Pump Number AI 207 AI 207 30237 HSC_AI_XXX[211] nvoRmPpLg3Nm_XXX SNVT_count_inc_f
Alarm Word 1 Value AI 208 AI 208 30300 HSC_AI_XXX[212] nvoAlm1Val_XXX SNVT_count_inc_f
Alarm Word 2 Value AI 209 AI 209 30301 HSC_AI_XXX[213] nvoAlm2Val_XXX SNVT_count_inc_f
Digital Input Word Value AI 210 AI 210 30302 HSC_AI_XXX[214] nvoDIWordVal_XXX SNVT_count_inc_f
Digital Output Word 1 Value AI 211 AI 211 30303 HSC_AI_XXX[215] nvoDO1Value_XXX SNVT_count_inc_f
Digital Output Word 2 Value AI 212 AI 212 30304 HSC_AI_XXX[216] nvoDO2Value_XXX SNVT_count_inc_f
Number of Cond Boilers Running AI 213 AI 213 30305 HSC_AI_XXX[217] nvoNmCBlrRun_XXX SNVT_count_inc_f
Number of Cond Boilers Requested AI 214 AI 214 30306 HSC_AI_XXX[218] nvoNmCBlrReq_XXX SNVT_count_inc_f
Number of Non-Cond Boilers Running AI 215 AI 215 30307 HSC_AI_XXX[219] nvoNmNCBlRun_XXX SNVT_count_inc_f
Number of Non-Cond Boilers Requested AI 216 AI 216 30308 HSC_AI_XXX[220] nvoNmNCBlReq_XXX SNVT_count_inc_f
Number of Cond Boilers in System AI 217 AI 217 30309 HSC_AI_XXX[221] nvoNmCBlrSys_XXX SNVT_count_inc_f
Number of Non-Cond Boilers in System AI 218 AI 218 30310 HSC_AI_XXX[222] nvoNmNCBlSys_XXX SNVT_count_inc_f
Cond Lead Boiler Number AI 219 AI 219 30311 HSC_AI_XXX[223] nvoCLdBlrNum_XXX SNVT_count_inc_f
Cond Lag1 Boiler Number AI 220 AI 220 30312 HSC_AI_XXX[224] nvoCLg1BlrNm_XXX SNVT_count_inc_f
Cond Lag2 Boiler Number AI 221 AI 221 30313 HSC_AI_XXX[225] nvoCLg2BlrNm_XXX SNVT_count_inc_f
Cond Lag3 Boiler Number AI 222 AI 222 30314 HSC_AI_XXX[226] nvoCLg3BlrNm_XXX SNVT_count_inc_f
Cond Lag4 Boiler Number AI 223 AI 223 30315 HSC_AI_XXX[227] nvoCLg4BlrNm_XXX SNVT_count_inc_f
Cond Lag5 Boiler Number AI 224 AI 224 30316 HSC_AI_XXX[228] nvoCLg5BlrNm_XXX SNVT_count_inc_f
Cond Lag6 Boiler Number AI 225 AI 225 30317 HSC_AI_XXX[229] nvoCLg6BlrNm_XXX SNVT_count_inc_f
Cond Lag7 Boiler Number AI 226 AI 226 30318 HSC_AI_XXX[230] nvoCLg7BlrNm_XXX SNVT_count_inc_f
Cond Lag8 Boiler Number AI 227 AI 227 30319 HSC_AI_XXX[231] nvoCLg8BlrNm_XXX SNVT_count_inc_f
Cond Lag9 Boiler Number AI 228 AI 228 30320 HSC_AI_XXX[232] nvoCLg9BlrNm_XXX SNVT_count_inc_f
Non-Cond Lead Boiler Number AI 229 AI 229 30321 HSC_AI_XXX[233] nvoNCLdBlrNm_XXX SNVT_count_inc_f
Non-Cond Lag1 Boiler Number AI 230 AI 230 30322 HSC_AI_XXX[234] nvoNCLg1BlNm_XXX SNVT_count_inc_f
Non-Cond Lag2 Boiler Number AI 231 AI 231 30323 HSC_AI_XXX[235] nvoNCLg2BlNm_XXX SNVT_count_inc_f
Non-Cond Lag3 Boiler Number AI 232 AI 232 30324 HSC_AI_XXX[236] nvoNCLg3BlNm_XXX SNVT_count_inc_f
Non-Cond Lag4 Boiler Number AI 233 AI 233 30325 HSC_AI_XXX[237] nvoNCLg4BlNm_XXX SNVT_count_inc_f
Non-Cond Lag5 Boiler Number AI 234 AI 234 30326 HSC_AI_XXX[238] nvoNCLg5BlNm_XXX SNVT_count_inc_f
Non-Cond Lag6 Boiler Number AI 235 AI 235 30327 HSC_AI_XXX[239] nvoNCLg6BlNm_XXX SNVT_count_inc_f
Non-Cond Lag7 Boiler Number AI 236 AI 236 30328 HSC_AI_XXX[240] nvoNCLg7BlNm_XXX SNVT_count_inc_f
Non-Cond Lag8 Boiler Number AI 237 AI 237 30329 HSC_AI_XXX[241] nvoNCLg8BlNm_XXX SNVT_count_inc_f
Non-Cond Lag9 Boiler Number AI 238 AI 238 30330 HSC_AI_XXX[242] nvoNCLg9BlNm_XXX SNVT_count_inc_f
Damper Mod 1 Input (Prove) Data AI 239 AI 239 30340 HSC_AI_XXX[243] nvoDmpMd1Inp_XXX SNVT_count_inc_f
Damper Mod 1 Output (Reqired) Data AI 240 AI 240 30341 HSC_AI_XXX[244] nvoDmpMd1Out_XXX SNVT_count_inc_f
Damper Mod 2 Input (Prove) Data AI 241 AI 241 30342 HSC_AI_XXX[245] nvoDmpMd2Inp_XXX SNVT_count_inc_f
Damper Mod 2 Output (Reqired) Data AI 242 AI 242 30343 HSC_AI_XXX[246] nvoDmpMd2Out_XXX SNVT_count_inc_f
Damper Mod 3 Input (Prove) Data AI 243 AI 243 30344 HSC_AI_XXX[247] nvoDmpMd3Inp_XXX SNVT_count_inc_f
Damper Mod 3 Output (Reqired) Data AI 244 AI 244 30345 HSC_AI_XXX[248] nvoDmpMd3Out_XXX SNVT_count_inc_f
HSC Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
EIP Tag Name Lon Name Lon SNVT Type
