CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
750-426 59
Damper Mod 4 Input (Prove) Data AI 245 AI 245 30346 HSC_AI_XXX[249] nvoDmpMd4Inp_XXX SNVT_count_inc_f
Damper Mod 4 Output (Reqired) Data AI 246 AI 246 30347 HSC_AI_XXX[250] nvoDmpMd4Out_XXX SNVT_count_inc_f
Cond Boiler Header Temp AI 252 AI 252 40280 HSC_AR_XXX[0] nvoCBlrHdrTp_XXX SNVT_temp_p
Main Supply Header Temp AI 253 AI 253 40282 HSC_AR_XXX[1] nvoMnSpHdrTp_XXX SNVT_temp_p
System Return Temp AI 254 AI 254 40284 HSC_AR_XXX[2] nvoSysRetTmp_XXX SNVT_temp_p
OA Temp or Remote Analog SP Value AI 255 AI 255 40286 HSC_AR_XXX[3] nvoOATRmSPVl_XXX SNVT_count_inc_f
DHW Setpoint AI 256 AI 256 40300 HSC_AR_XXX[4] nvoDHW_SP_XXX SNVT_count_inc_f
Cold Building Setpoint AI 257 ADF 1 40304 HSC_AR_XXX[5] nvoColdBldSP_XXX SNVT_count_inc_f
Remote Analog Input Setpoint Value AI 258 ADF 2 40306 HSC_AR_XXX[6] nviRemAISPVl_XXX SNVT_count_inc_f
* Remote Modbus Setpoint Value AV 1 AO 1 40308 HSC_AWR_XXX[0] nviRemMdSPVl_XXX SNVT_count_inc_f
* Remote Modbus Outdoor Air Temp AV 2 AO 2 40310 HSC_AWR_XXX[1] nviRemMd_OAT_XXX SNVT_temp_p
* Remote Modbus System Enable AV 3 AO 3 40312 HSC_AWR_XXX[2] nviRmMdSysEn_XXX SNVT_count_inc_f
* Modbus Heartbeat AV 4 AO 4 40314 HSC_AWR_XXX[3] nvoModHrtbt_XXX SNVT_count_inc_f
Deadband Cond/Non-Cond Mode Sw Temp AI 259 ADF 3 40318 HSC_AR_XXX[7] nvoDeadband_XXX SNVT_temp_p
OA Temp Low Value for Reset Curve AI 260 ADF 4 40320 HSC_AR_XXX[8] nvoOATLoVal_XXX SNVT_temp_p
OA Temp High Value for Reset Curve AI 261 ADF 5 40322 HSC_AR_XXX[9] nvoOATHiVal_XXX SNVT_temp_p
Loop Setpoint at Cold (low) OAT AI 262 ADF 6 40324 HSC_AR_XXX[10] nvoLpSPCold_XXX SNVT_temp_p
Loop Setpoint at Warm (high) OAT AI 263 ADF 7 40326 HSC_AR_XXX[11] nvoLpSPWarm_XXX SNVT_temp_p
Min Inlet Temp for Non-Cond Boilers AI 264 ADF 8 40328 HSC_AR_XXX[12] nvoMnInTp_NC_XXX SNVT_temp_p
Non-Cond Reset Shift AI 265 ADF 9 40336 HSC_AR_XXX[13] nvoNCResShft_XXX SNVT_count_inc_f
NC/Cond Switch Temp AI 266 ADF 10 40338 HSC_AR_XXX[14] nvoNC_CSwTmp_XXX SNVT_temp_p
Read only NC Header SP (active) AI 267 ADF 11 40340 HSC_AR_XXX[15] nvoNCHeadrSP_XXX SNVT_count_inc_f
Read only Cond Header SP (active) AI 268 ADF 12 40342 HSC_AR_XXX[16] nvoCHeaderSP_XXX SNVT_count_inc_f
System Mode AI 312 ADF 13 40344 HSC_AR_XXX[17] nvoSysMode_XXX SNVT_count_inc_f
Cond Boiler Status AI 313 ADF 14 40345 HSC_AR_XXX[18] nvoCBlrStat_XXX SNVT_count_inc_f
Non-Cond Boiler Status AI 314 ADF 15 40346 HSC_AR_XXX[19] nvoNCBlStat_XXX SNVT_count_inc_f
Firing rate for Cond boiler group AI 269 ADF 16 40348 HSC_AR_XXX[20] nvoFirRtCBlr_XXX SNVT_count_inc_f
Firing rate for non-Cond boiler group AI 270 ADF 17 40350 HSC_AR_XXX[21] nvoFirRtNCBl_XXX SNVT_count_inc_f
Warm Weather Shutdown Temp AI 271 ADF 18 40352 HSC_AR_XXX[22] nvoWmWtrShTp_XXX SNVT_temp_p
Cond Boiler 1 Run Hours AI 272 ADF 19 40390 HSC_AD_XXX[0] nvoCBl1RunHr_XXX SNVT_time_hour
Cond Boiler 2 Run Hours AI 273 ADF 20 40392 HSC_AD_XXX[1] nvoCBl2RunHr_XXX SNVT_time_hour
Cond Boiler 3 Run Hours AI 274 ADF 21 40394 HSC_AD_XXX[2] nvoCBl3RunHr_XXX SNVT_time_hour
Cond Boiler 4 Run Hours AI 275 ADF 22 40396 HSC_AD_XXX[3] nvoCBl4RunHr_XXX SNVT_time_hour
Cond Boiler 5 Run Hours AI 276 ADF 23 40398 HSC_AD_XXX[4] nvoCBl5RunHr_XXX SNVT_time_hour
Cond Boiler 6 Run Hours AI 277 ADF 24 40400 HSC_AD_XXX[5] nvoCBl6RunHr_XXX SNVT_time_hour
Cond Boiler 7 Run Hours AI 278 ADF 25 40402 HSC_AD_XXX[6] nvoCBl7RunHr_XXX SNVT_time_hour
Cond Boiler 8 Run Hours AI 279 ADF 26 40404 HSC_AD_XXX[7] nvoCBl8RunHr_XXX SNVT_time_hour
Cond Boiler 9 Run Hours AI 280 ADF 27 40406 HSC_AD_XXX[8] nvoCBl9RunHr_XXX SNVT_time_hour
Cond Boiler 10 Run Hours AI 281 ADF 28 40408 HSC_AD_XXX[9] nvoCBl10RnHr_XXX SNVT_time_hour
Non-Cond Boiler A Run Hours AI 282 ADF 29 40410 HSC_AD_XXX[10] nvoNCBlARnHr_XXX SNVT_time_hour
Non-Cond Boiler B Run Hours AI 283 ADF 30 40412 HSC_AD_XXX[11] nvoNCBlBRnHr_XXX SNVT_time_hour
Non-Cond Boiler C Run Hours AI 284 ADF 31 40414 HSC_AD_XXX[12] nvoNCBlCRnHr_XXX SNVT_time_hour
Non-Cond Boiler D Run Hours AI 285 ADF 32 40416 HSC_AD_XXX[13] nvoNCBlDRnHr_XXX SNVT_time_hour
Non-Cond Boiler E Run Hours AI 286 ADF 33 40418 HSC_AD_XXX[14] nvoNCBlERnHr_XXX SNVT_time_hour
Non-Cond Boiler F Run Hours AI 287 ADF 34 40420 HSC_AD_XXX[15] nvoNCBlFRnHr_XXX SNVT_time_hour
Non-Cond Boiler G Run Hours AI 288 ADF 35 40422 HSC_AD_XXX[16] nvoNCBlGRnHr_XXX SNVT_time_hour
Non-Cond Boiler H Run Hours AI 289 ADF 36 40424 HSC_AD_XXX[17] nvoNCBlHRnHr_XXX SNVT_time_hour
Non-Cond Boiler I Run Hours AI 290 ADF 37 40426 HSC_AD_XXX[18] nvoNCBlIRnHr_XXX SNVT_time_hour
Non-Cond Boiler J Run Hours AI 291 ADF 38 40428 HSC_AD_XXX[19] nvoNCBlJRnHr_XXX SNVT_time_hour
Cond Boiler 1 Run Cycles AI 292 ADF 39 40430 HSC_AD_XXX[20] nvoCBl1RunCy_XXX SNVT_count_inc_f
HSC Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
EIP Tag Name Lon Name Lon SNVT Type
