CleaverBrooks ProtoNode User Manual

ProtoNode Gateway
88 750-426
DAB1[9]4 BI 149 DI 149 11499 nvoDAB1_9_4_XXX SNVT_switch
DAB1[9]5 BI 150 DI 150 11500 nvoDAB1_9_5_XXX SNVT_switch
DAB1[9]6 BI 151 DI 151 11501 nvoDAB1_9_6_XXX SNVT_switch
DAB1[9]7 BI 152 DI 152 11502 nvoDAB1_9_7_XXX SNVT_switch
DAB1[9]8 BI 153 DI 153 11503 nvoDAB1_9_8_XXX SNVT_switch
DAB1[9]9 BI 154 DI 154 11504 nvoDAB1_9_9_XXX SNVT_switch
DAB1[9]10 BI 155 DI 155 11505 nvoDAB1_9_10_XXX SNVT_switch
DAB1[9]11 BI 156 DI 156 11506 nvoDAB1_9_11_XXX SNVT_switch
DAB1[9]12 BI 157 DI 157 11507 nvoDAB1_9_12_XXX SNVT_switch
DAB1[9]13 BI 158 DI 158 11508 nvoDAB1_9_13_XXX SNVT_switch
DAB1[9]14 BI 159 DI 159 11509 nvoDAB1_9_14_XXX SNVT_switch
DAB1[9]15 BI 160 DI 160 11510 nvoDAB1_9_15_XXX SNVT_switch
Feed Pump 1 Run Time AI 1 AI 1 30853 nvoFdPm1RnTm_XXX SNVT_time_hour
Feed Pump 2 Run Time AI 2 AI 2 30855 nvoFdPm2RnTm_XXX SNVT_time_hour
Feed Pump 3 Run Time AI 3 AI 3 30857 nvoFdPm3RnTm_XXX SNVT_time_hour
Feed Pump 4 Run Time AI 4 AI 4 30859 nvoFdPm4RnTm_XXX SNVT_time_hour
Feed Pump 5 Run Time AI 5 AI 5 30861 nvoFdPm5RnTm_XXX SNVT_time_hour
Feed Pump 6 Run Time AI 6 AI 6 30863 nvoFdPm6RnTm_XXX SNVT_time_hour
DAR1[6] AI 7 AI 7 30865 nvoDAR1_6_XXX SNVT_time_sec
DAR1[7] AI 8 AI 8 30867 nvoDAR1_7_XXX SNVT_count_f
DAR1[8] AI 9 AI 9 30869 nvoDAR1_8_XXX SNVT_count_f
Stop Lag Feed Pump Limit AI 10 AI 10 30871 nvoStLgFdPLm_XXX SNVT_count_f
Alternate Feed Pumps AI 11 AI 11 30873 nvoAltFdPmps_XXX SNVT_time_hour
Start Chemical Feed Time Delay AI 12 AI 12 30875 nvoStrChFTDl_XXX SNVT_time_sec
Stop Chemical Feed Time Delay AI 13 AI 13 30877 nvoStpChFTDl_XXX SNVT_time_sec
DAR1[14] AI 14 AI 14 30879 nvoDAR1_14_XXX SNVT_count_f
Deaerator Temp AI 15 AI 15 30881 nvoDeaTmp_XXX SNVT_temp_p
Deaerator Tank Pressure AI 16 AI 16 30883 nvoDeaTnkPrs_XXX SNVT_count_f
Deaerator Tank Wtr Lvl AI 17 AI 17 30885 nvoDeaTnWtLv_XXX SNVT_count_f
Deaerator Feed Wtr (MUV) Signal AI 18 AI 18 30887 nvoDeaMUVSig_XXX SNVT_lev_percent
Deaerator Steam PRValve Signal AI 19 AI 19 30889 nvoDeaStPRVS_XXX SNVT_lev_percent
Boiler Feed Wtr Header Pressure AI 20 AI 20 30891 nvoBFdWtHdPr_XXX SNVT_count_f
Deaerator 2nd Feed Wtr (MUV) Signal AI 21 AI 21 30893 nvoDea2MUVSg_XXX SNVT_lev_percent
Start Lag Feed Pump Limit AI 22 AI 22 30895 nvoStrLgFPLm_XXX SNVT_count_f
DA Lvl - Pump Auto-Restart Lvl AI 23 AI 23 30897 nvoDALvPmAut_XXX SNVT_count_f
DAR1[24] AI 24 AI 24 30899 nvoDAR1_24_XXX SNVT_count_f
DAR1[25] AI 25 AI 25 30901 nvoDAR1_25_XXX SNVT_count_f
DAR1[26] AI 26 AI 26 30903 nvoDAR1_26_XXX SNVT_count_f
DAR1[27] AI 27 AI 27 30905 nvoDAR1_27_XXX SNVT_count_f
DAR1[28] AI 28 AI 28 30907 nvoDAR1_28_XXX SNVT_count_f
DAR1[29] AI 29 AI 29 30909 nvoDAR1_29_XXX SNVT_count_f
DAR1[30] AI 30 AI 30 30911 nvoDAR1_30_XXX SNVT_count_f
DAR1[31] AI 31 AI 31 30913 nvoDAR1_31_XXX SNVT_count_f
DAR1[32] AI 32 AI 32 30915 nvoDAR1_32_XXX SNVT_count_f
DAR1[33] AI 33 AI 33 30917 nvoDAR1_33_XXX SNVT_count_f
DAR1[34] AI 34 AI 34 30919 nvoDAR1_34_XXX SNVT_count_f
DAR1[35] AI 35 AI 35 30921 nvoDAR1_35_XXX SNVT_count_f
DAR1[36] AI 36 AI 36 30923 nvoDAR1_36_XXX SNVT_count_f
DAR1[37] AI 37 AI 37 30925 nvoDAR1_37_XXX SNVT_count_f
DAR1[38] AI 38 AI 38 30927 nvoDAR1_38_XXX SNVT_count_f
ADAC Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus and LonWorks (Continued)
RER LER
Point Name
BACnet
Data
Type
BACnet
Object Id
N2
Data
Type
N2 Point
Address
Modbus
Register
Lon Name Lon SNVT Type

CleaverBrooks ProtoNode Specifications

General

Brand	CleaverBrooks
Model	ProtoNode
Category	Gateway
Language	English
