CMC electronic Esterline CMA-5024 User Manual

INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page A.9
November 21, 2008
Oct.
Label
429 Parameter
Signal
Format
Units
Pos.
Sense
Range (j)
Sig.
Bits
Resolution
(j)
SDI
Used
(n)
Max (a) Tx
Intvl.
017 Selected Runway
Heading (h)
BCD DEG (b) +359.9 4 0.1 No Burst / 333
(m)
033 Landing System
Mode/Frequency (h)
BCD N/A N/A N/A N/A N/A Yes Burst / 333
(m)
040 Set Altitude (h) BCD FT UP ±79,999 5 1 No (c)
041 Set Latitude (h) BCD DEG/MIN N ±179:59.9
(i)
6 0.1 MIN No (c)
042 Set Longitude (h) BCD DEG/MIN E ±179:59.9 6 0.1 MIN No (c)
045 Msg Block Start (h) Block N/A N/A 8192 N/A N/A Yes (l)
046 Msg Block Body (h) Block N/A N/A N/A N/A N/A Yes (l)
105 Selected Runway
Heading
BNR DEG CW-N ±180 11
≅0.0879
No Burst / 333
(m)
125 UTC BCD HR:MIN (b) 23:59.9 5 0.1 MIN No 1200 (f)
143 Dest Long BNR DEGREES E ±180 18
≅6.87E-4
Yes Burst(g)
144 Dest Lat BNR DEGREES N ±180 (i) 18
≅6.87E-4
Yes Burst(g)
146(e) Sat De-Sel #1 (h) DISC N/A N/A N/A N/A N/A Yes Burst (g)
150 UTC (h) BNR HR:MIN:S (b) 23:59.59 17 1.0 SEC No 200
151 Flight Leg (h) DISC N/A N/A N/A N/A N/A No 1200
152 Dest ETA (h) BNR HR:MIN (b) 23:59 11 1 MIN Yes Burst(g)
167(e) Alt ETA (h) BNR HR:MIN (b) 23:59 11 1 MIN Yes Burst(g)
170(e) Sat De-Sel #2 (h) DISC N/A N/A N/A N/A N/A Yes Burst(g)
203 Pressure Altitude BNR FT UP ±131,072 17 1 No 62.5
210 True Air Speed BNR KNOTS (b) 2048 15 0.0625 No 125
214(e) Alt Lat BNR DEGREES N ±180 (i) 18
≅6.87E-4
Yes Burst(g)
216(e) Alt Long BNR DEGREES E ±180 18
≅6.87E-4
Yes Burst(g)
227(q) Command Summary
Word (h)
Packed N/A N/A N/A N/A N/A Yes Burst /
1200 (p)
232 Airport ID #1 (h) DISC N/A N/A N/A N/A N/A Yes Burst (m)
255 Airport ID #2 (h) DISC N/A N/A N/A N/A N/A Yes Burst (m)
260 Date (h) BCD D:M:YR (b) 31:12:99 6 1 DAY No 1200
305(o) SBAS PA Mode & SP
Selection (h)
DISC N/A N/A N/A N/A N/A Yes 333
310 Latitude BNR DEGREES N ±180 (i) 20
≅1.72E-4
No 200
311 Longitude BNR DEGREES E ±180 20
≅1.72E-4
No 200
312 Ground Speed BNR KNOTS (b) 4096 15 0.125 No 100
313 Tk Angle True BNR DEGREES CW-N ±180 15
≅5.49E-3
No 50
314 True Heading BNR DEGREES CW-N ±180 15
≅5.49E-3
No 50
324 Pitch Angle BNR DEGREES Nose
Up
±180 15
≅5.49E-3
No 100
325 Roll Angle BNR DEGREES RW
Down
±180 15
≅5.49E-3
No 100
352 Maint. Discrete #1 (h) DISC N/A N/A N/A N/A N/A Yes 1200
361 Altitude - Inertial BNR FT UP ±131,072 20 0.125 No 40
365 Vertical Speed BNR FT/MIN UP ±32,768 15 1 No 40
Figure A-2. ARINC 429 IRS/FMS Input Bus Data Labels
34-52-81-1
