INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page E.21
November 21, 2008
PARAMETER ASSOCIATED LABELS
246 & 247 Ground Station Identifier (DME data)
300
1.3 PRE-DEFINED APD FILES PER GLSSU PART NUMBER
This section defines the APD files for each GLSSU part numbers covered by this manual. Each
configuration is defined using 5 tables. Each table is identified by the APD Configuration number and
the APD CID part number.
A. APD File for GLSSU Part Number 100-601967-100 (APD CID 169-615462-000)
This APD File includes 16 APD Configurations, summarized in 5 tables plus a table below
containing the CRC values to be used for checking the data validity; refer to section 1.2 above for
detailed descriptions and format information. Convention: 0 == OFF, 1 == ON.
APD
CONFIGURATION
CRC VALUE
(HEXADECIMAL)
APD
CONFIGURATION
CRC VALUE
(HEXADECIMAL)
#0 FB1A2028 #8 4E8B1FEC
#1 A22EDDA0 #9 AFF257A5
#2 AB834EB8 #10 718ED367
#3 9A251CBC #11 98F072B7
#4 EEE20B3F #12 0E7FB792
#5 2CD16384 #13 E7011642
#6 5E944469 #14 BC84C9FD
#7 BFED0C20 #15 A2389BA6
GLSSU P/N 100-601967-100
APD CID 169-615462-000 CRC value for the APD File: DBF33679
A brief description of each APD Configuration and of its intended use follows:
(1) APD #0: ARINC-743A-4 Configuration with Manual mode transition
Navigation connector J1 ARINC 743A-4 compatible. For use En Route and for approach
type LNAV using Navigation connector J1 only with ARINC 743A-4 compatible I/O. No
automatic mode transition to SBAS PA.
(2) APD #1: CMA-3012 GNSSU configuration with Manual mode transition
Navigation connector J1 ARINC 743-4 compatible. No output of labels 057 and 370. No
automatic mode transition to SBAS PA. Otherwise identical to APD #0.
(3) APD #2: ARINC-743A-4 Configuration with Automatic mode transition
Navigation connector J1 ARINC 743A-4 compatible, plus automatic mode transition to SBAS
PA when an approach is selected. The Air/Ground Indicator Type APD is set at On.
Otherwise identical to APD #0.
34-52-81-1
