INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page 115
November 21, 2008
(J3) PIN SIGNAL NAME DESCRIPTION (FOR REFERENCE)
21 N/A (Do not connect)
22 N/A (Do not connect)
RS 422 data input
25 N/A (Do not connect)
26 N/A (Do not connect)
RS 422 data output
23 N/A (Do not connect)
24 N/A (Do not connect)
RS 422 data input
27 N/A (Do not connect)
28 N/A (Do not connect)
RS 422 data output
29 N/A (Do not connect)
30 N/A (Do not connect)
RS 422 data input
33 N/A (Do not connect)
34 N/A (Do not connect)
RS 422 data output
31 N/A (Do not connect)
32 N/A (Do not connect)
RS 422 data input
35 N/A (Do not connect)
36 N/A (Do not use)
RS 422 data output
46 429 out ILS Look-Alike #1 HI
47 429 out ILS Look-Alike #1 LO
ARINC 429 ILS data output
48 429 out ILS Look-Alike #2 HI
49 429 out ILS Look-Alike #2 LO
ARINC 429 ILS data output
50 429 out DME Look-Alike #1 HI
51 429 out DME Look-Alike #1 LO
ARINC 429 DME data output
52 429 out DME Look-Alike #2 HI
53 429 out DME Look-Alike #2 LO
ARINC 429 DME data output
41 429 in DME #1 HI
42 429 in DME #1 LO
ARINC 429 DME data input
43 429 in DME #2 HI
44 429 in DME #2 LO
ARINC 429 DME data input
37 429 in ILS #1 HI
38 429 in ILS #1 LO
ARINC 429 ILS data input
39 429 in ILS #2 HI
40 429 in ILS #2 LO
ARINC 429 ILS data input
18 ILS/GLS Source Select input Open = The HIS passes-through the ILS and DME input data.
Ground = The HIS substitutes selectively the GLS data to the ILS
and DME input data
19 N/A (Do not connect) Spare remote Discrete Input
20 N/A (Do not connect) Spare remote Discrete Input
5 ILS Select Discrete Output * Ground = The pin 18 is set to "ILS", Opened otherwise.
4 GLS Select Discrete Output * Ground = The pin 18 is set to "GLS", Opened otherwise.
3 Chassis GND Ground; same as J1 pin 33. Connect to good aircraft ground
1 28V HIS Input Optional HIS power input; connect to positive side of aircraft DC
power supply through a 1.5 A minimum breaker. Normal operating
voltage is +22 to +36 VDC.
2 28V HIS Return Optional HIS power input; return; connect to negative side of
aircraft DC power supply. The power input is isolated from the
chassis (floating) and from the chassis ground pins J1-33, J3-3.
* Contact closure to ground; rating: 280 mADC (closed) & 36 VDC (open) maximum
Figure 109. Pin Assignments for J3; HIS Interfaces
34-52-81-1
