INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page C.23
November 21, 2008
1.38 Labels 301 to 303 - Aircraft Identification Words - Input
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-25 ISO #5 Character #3 (Label 301)
ISO #5 Character #6 (Label 302)
ISO #5 Character #9 (Label 303)
24-18 ISO #5 Character #2 (Label 301)
ISO #5 Character #5 (Label 302)
ISO #5 Character #8 (Label 303)
17-11 ISO #5 Character #1 (Label 301)
ISO #5 Character #4 (Label 302)
ISO #5 Character #7 (Label 303)
10-9 SDI Always = 00
8-1 Octal Label 301, 302, or 303
1.39 Label 305 - SBAS PA Mode & Service Provider Selection - Input/Output
This label is configurable by the APD Configuration.
ARINC BIT DESCRIPTION SETTING NOTE
32 Parity Odd
31-30 SSM Normal Operation = 00
No Computed Data = 01
Functional Test = 10
Failure Warning = 11
29 SBAS PA Mode Selection Enter SBAS PA Mode =1
Exit SBAS PA Mode =0
1
28 - 25 SBAS PA Mode Service Provider ID 0 - 15 2,3
24 Navigation Service Prov. 0 De-select =1 Enable =0
23 Navigation Service Prov. 1 De-select =1 Enable =0
22 Navigation Service Prov. 2 De-select =1 Enable =0
21 Navigation Service Prov. 3 De-select =1 Enable =0
20 Navigation Service Prov. 4 De-select =1 Enable =0
19 Navigation Service Prov. 5 De-select =1 Enable =0
18 Navigation Service Prov. 6 De-select =1 Enable =0
17 Navigation Service Prov. 7 De-select =1 Enable =0
16 Navigation Service Prov. 8 De-select =1 Enable =0
15 Navigation Service Prov. 9 De-select =1 Enable =0
14 Navigation Service Prov. 10 De-select =1 Enable =0
13 Navigation Service Prov. 11 De-select =1 Enable =0
12 Navigation Service Prov. 12 De-select =1 Enable =0
11 Navigation Service Prov. 13 De-select =1 Enable =0
10-9 Source/Destination Identifier All Call = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 305 (configurable by APD)
34-52-81-1
