CMC electronic Esterline CMA-5024 User Manual

INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page 104
November 21, 2008
0503001
DO NOT PAINT
GPS
O RING GROOVE MS28775-142
.55
.141
4.70
.800
1.600
3
.
00
1.650
3.300
C
L
C
L
TYPE TNC
.73
.229
.218
C' SINK .385 DIAX 100
4 PLACES
DIA
.141
R 8.0
0
NOTE: Weight = 0.25 kg (0.56 lbs)
All dimensions are in inches
Figure 102. Typical GPS/SBAS antenna (for reference)
34-52-81-1
