INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page C.8
November 21, 2008
ARINC BIT DESCRIPTION SETTING
10-9 Source/Destination Identifier Not Used = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 060
Note 1: When a satellite is removed from the solution because it is below the C/No threshold or it is
isolated, bit 23 is set to zero (invalid).
Note 2: GPS SV PRN: 1-32; SBAS SV PRN: 38-56 for 120-138, Reserved SV PRN: 0, 33-37, 57-63.
Note 3: Only delta-range measurements are used. This bit is forced to 1.
Note 4: When the SBAS Range Offset APD Label ID Assignment is set to a non-zero value (label is
output) and the SBAS Range Offset conversion is compatible with SBAS PA mode, bit 20 is
set to 1; otherwise this bit is set to 0. This bit does not supersede bit 23. The setting of 0 when
the SBAS Range Offset APD Label ID Assignment is set to 0 corresponds to the legacy
encoding for a C/A code measurement.
Note 5: Only the GPS system is supported. This bit is forced to 0.
1.14 Label 126 - Flight Phase Word - Input
ARINC BIT DESCRIPTION SETTING
Bit 32 Parity Odd
Bit 31-30 SSM Failure Warning =00
No Computed Data =01
Functional Test =10
Normal Operation =11
Bit 29-15 Padding (forced = 0)
Bit 14-11 Flight Phase 0000 = Not Defined
0001 = Power-On
0010 = Engine Start
0011 = Taxi Out
0100 = Takeoff Roll
0101 = Initial Climb
0110 = Climb
0111 = Cruise
1000 = Descent
1001 = Approach
1010 = Go Around
1011 = Flare
1100 = Rollout
1101 = Taxi In
1110 = Engine Shutdown
1111 = Maintenance
Bit 10, 9 SDI: (Always = 00)
Bit 8-1 Octal Label 126
