INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page C.18
November 21, 2008
1.29 Label 243 - GLS Runway Selection - Output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 SSM Normal Operation = 00
No Computed Data = 01
Functional Test = 10
Fail Warning = 11
29,28 Spare =0
27 - 22 Runway Number 0 -36
21 , 20 Runway Letter None = 0 0
R = 0 1
C = 1 0
L = 1 1
19 - 15 Route Indicator ISO#5 Character (See note)
14 - 11 Reserved =0
10-9 SDI Not Used = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 243
Note: The Route Indicator is encoded with the lower 5 bits of the ISO#5 character set, using upper
case alpha set A - Z, excluding the characters 'I' and 'O' but including the 'space' character
(00000 binary on 5 bits).
1.30 Labels 246 & 247 - DME Ground Station Identifier Words 1 & 2 - Output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 SSM Normal Operation = 00
No Computed Data = 01
Functional Test = 10
Fail Warning = 11
29 - 27 Spare = 0 0 0
26 Pad = 0
25 - 19 Ground Stn. Ident. Char. #2 / #4 ISO#5 Character as per Look-Alike
DME Ground Station Identifier APD
18 Pad = 0
17 - 11 Ground Stn. Ident. Char. #1 / #3 ISO#5 Character as per Look-Alike
DME Ground Station Identifier APD
10-9 SDI Not Used = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 246 & 247 (DME)
Note: Label 246 contains characters 1 and 2, and Label 247 contains characters 3 and 4.
34-52-81-1
