INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page C.26
November 21, 2008
1.42 Label 352 - Maintenance Discrete 1 - Input/Output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 Sign Status Matrix (SSM) Normal Operation = 00
No Computed Data = 01
Functional Test = 10
Failure Warning = 11
29 Air/Ground Indicator In Air = 1
On Ground = 0
28-24 GLSSU Operational Mode Self-Test
Initialization
Acquisition
Navigation
SBAS Navigation
SBAS PA
Altitude Aiding
Reserved
Aided
Fault
= 00000
= 00100
= 01000
= 01100
= 01101
= 01111
= 10000
= 10100
= 11000
= 11111
23 Spare = 0
22 Approach Monitor Active Inactive = 0 Active = 1
21 Vertical Approach Monitor Inactive or within limit = 0
Active and outside limit = 1
20 Lateral Approach Monitor Inactive or within limit = 0
Active and outside limit = 1
19 Antenna 0 = Normal Op
1 = Fail
18 GLS/GPS ARINC 429
Output #3
0 = Normal Op
1 = Fail
17 GLS/GPS ARINC 429
Output #2
0 = Normal Op
1 = Fail
16 GLS/GPS ARINC 429
Output #1
0 = Normal Op
1 = Fail
15 Active Database Cycle 0 = Second Cycle
1 = First Cycle
14 Reserved = 0
13 SDI Center Approach
Mismatch
No Mismatch = 0
Mismatch = 1
12 APD Mismatch No Mismatch = 0
Mismatch = 1
11 Deviation Output Labels 0 = Normal Op
1 = Fail
10-9 Source/Destination Identifier All Call = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 352
34-52-81-1
