INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page C.20
November 21, 2008
1.33 Label 260 - Date - Input/Output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 Sign Status Matrix (SSM) Normal Operation = 00
No Computed Data = 01
Functional Test = 10
Not Used = 11
29-28 Tens of Days 0 - 3
27-24 Units of Days 0 - 9
23 Tens of Months 0 - 1
22-19 Units of Months 0 - 9
18-15 Tens of Years 0 - 9
14-11 Units of Years 0 - 9
10-9 Source/Destination Identifier Not Used = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 260
1.34 Labels 263 & 264 - Approach Identifier Words 1 & 2 - Output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 SSM Normal Operation = 00
No Computed Data = 01
Functional Test = 10
Fail Warning = 11
29 - 27 Spare = 0 0 0
26 Pad = 0
25 - 19 Approach Ident. Char. #2 / #4 ISO#5 Character
18 Pad = 0
17 - 11 Approach Ident. Char. #1 / #3 ISO#5 Character
10-9 SDI Not Used = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 263 and 264
Note 1: The Approach Identifier output on the GLS bus is synonymous with the Reference Path
Identifier defined in the FAS Data Block.
Note 2: Label 263 contains characters 1 and 2, and Label 264 contains characters 3 and 4.
Note 3: When output on the ILS Look-Alike Bus, instead of the Approach Identifier, the Look-Alike ILS
Ground Station Identifier as per APD is encoded (same encoding as for Labels 242 & 244).
