INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page C.7
November 21, 2008
1.12 Label 056 - URA Offset - Output
ARINC BIT DESCRIPTION SETTING
32 Parity (odd)
31-30 Sign Status Matrix (SSM) Failure Warning = 00
No Computed Data = 01
Functional Test = 10
Normal Operation = 11
29 Sign bit Positive = 0
Negative = 1
28-21 URA Ionospheric Offset -128 to +127.5 (LSB weight 0.5)
20 Sign bit Positive = 0
Negative = 1
19-12 URA Range Offset -128 to +127.5 (LSB weight 0.5)
11 SBAS Correction Source Toggle upon change in correction source
10-9 Source/Destination Identifier Not Used = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 56
The SBAS Correction Source bit will toggle each time the SBAS PRN that is providing the corrections
(ionospheric or range) changes with respect to the last measurement block transmitted. The value
when the label is first transmitted (or transmission re-starts) with SSM at Normal Operation provides no
information on the correction source.
1.13 Label 060 - GLSSU Measurement Status - Output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 Sign Status Matrix (SSM) Normal Operation = 00
No Computed Data = 01
Functional Test = 10
Failure Warning = 11
29-24 SVID (PRN Code No.)
(See Note 2)
0 to 63; (00Hex to 3FHex)
23 SVID Status/Isolation
(See Note 1)
Valid = 1
Invalid/Isolated = 0
22 Range Rate or Delta-Range Status Valid = 1
Invalid = 0
21 Rate Measurement Type
(See Note 3)
Delta-Range Meas = 1
Doppler Measurement = 0
20 SBAS PA mode compatibility
(See Note 4)
Compatible = 1
Not Compatible = 0
19 User Clock Update Clock Update = 1
No Clock Update = 0
18 Satellite Position Data Used Ephemeris Data Used = 1
Almanac Data Used = 0
17-12 C/N
o
Range = 0-63 (00Hex to 3FHex) dB-Hz
Resolution = 1 dB-Hz
11 System
(See Note 5)
GLONASS (reserved) = 1
GPS (forced to 0) = 0
34-52-81-1
