INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page C.27
November 21, 2008
1.43 Label 355 - GNSS Fault Summary - Input/Output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 Sign Status Matrix (SSM) Normal Operation = 00
No Computed Data = 01
Functional Test = 10
Failure Warning = 11
29 Command Word Acknowledge (Note 1) No Acknowledge = 0 Acknowledge = 1
28 Test Inhibit Test Allowed =0 Inhibited =1
27* Sensor Unit Normal Op =0 Fail =1
26* RF Input Normal Op =0 Fail =1
25* GPS Normal Op =0 Fail =1
24 IRS/FMS Bus No. 1 Normal Op =0 No Bus Activity =1
23 IRS/FMS Bus No. 2 Normal Op =0 No Bus Activity =1
22 FMS/DADS Bus No. 1 Normal Op =0 No Bus Activity =1
21 FMS/DADS Bus No. 2 Normal Op =0 No Bus Activity =1
20 Gen Purpose/Differential Bus No. 1 Normal Op =0 No Bus Activity =1
19 Gen Purpose/Differential Bus No. 2 Normal Op =0 No Bus Activity =1
18 OMS Bus (Note 2) Normal Op =0 No Bus Activity =1
17 ILS #1 Bus Normal Op =0 No Bus Activity =1
16 ILS #2 Bus Normal Op =0 No Bus Activity =1
15 DME #1 Bus Normal Op =0 No Bus Activity =1
14 DME #2 Bus Normal Op =0 No Bus Activity =1
13 Freq/Function Data Source Bus Normal Op =0 No Bus Activity =1
12 X-Talk Bus No. 1 Normal Op =0 No Bus Activity =1
11 X-Talk Bus No. 2 Normal Op =0 No Bus Activity =1
10-9 Source/Destination Identifier All Call = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 355
* Fault bits 25, 26, 27 are defined as follows:
27 - Faults which can be isolated to the sensor unit.
26 - Faults which can be isolated to the RF input (connector, cable or antenna).
25 - Faults which cannot be isolated between the sensor and the RF input.
Note 1: Bit 29 is only used to acknowledge Command Summary Word requests to transmit
Maintenance Messages.
Note 2: Bit 18 is reserved for IRS Bus No. 3 in ARINC 743A-4.
34-52-81-1
