INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page C.28
November 21, 2008
1.44 Label 356 - Maintenance Message - Input/Output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-25 ISO #5 Data character: Initial word = STX
First Inter. Word = SYN
Intermediate word = Ch #3
Final word = Ch #3
24-17 (Initial Word only) = zeros
16-9 (Initial Word only) = # of 32
Bit Words
24 Pad (Intermediate/Final Words) = zero
23-17 Binary Total # of Pages
--------------------------------
ISO #5 Data Character #2
(First Intermediate Word)
-----------------------------------------
(Intermediate/Final Word)
16 Pad (Intermediate/Final Word) = zero
15-9 Binary Present Page
--------------------------------
ISO #5 Data Character #1
(First Intermediate Word)
-----------------------------------------
(Intermediate/Final Word)
8-1 Octal Label 356
Note: The information in this label is to be transmitted using the ISO #5 character set.
1.45 Label 377 - GLSSU Equipment ID - Input/Output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 Sign Status Matrix (SSM) Normal Operation = 00
No Computed Data = 01
Functional Test = 10
Failure Warning = 11
29-23 Spares (forced = 0)
22-11 Equipment Identity 00B hex (Note 1)
10-9 Source/Destination Identifier Not used = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 377
Note 1: The Equipment ID is configurable by the GPS Bus Equipment ID and GLS Bus Equipment ID
APD.
