INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page C.11
November 21, 2008
ARINC BIT DESCRIPTION SETTING
Enable =0
18 SVID 12 De-select =1
Enable =0
17 SVID 13 De-select =1
Enable =0
16 SVID 14 De-select =1
Enable =0
15 SVID 15 De-select =1
Enable =0
14 SVID 16 De-select =1
Enable =0
13-12 Reserved
11 De-selection type Destination Predictive RAIM =0
Alternate Predictive RAIM =1
10-9 SDI: All Call = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 126/146
1.19 Label 150 - Binary UTC - Input/Output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 Sign Status Matrix (SSM) Failure Warning = 00
No Computed Data = 01
Functional Test = 10
Normal Operation = 11
29 Sign bit = 0 (positive)
28-24 MSC (Hours, Binary) = 0-23
23-18 Digit (Minutes, Binary) = 0-59
17-12 Digit (Seconds, Binary) = 0-59
11 Indicates precision time = 1
10-9 Source/Destination Identifier Not used = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 150
