INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page C.5
November 21, 2008
1.8 Label 041 - Set Latitude – Input
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 Sign Status Matrix (SSM) Positive = 00
No Computed Data = 01
Functional Test = 10
Negative = 11
29 Undefined Always 0
28 - 25 Tens (Degrees) 0 - 9
24 - 21 Units (Degrees) 0 - 9
20 - 17 Tens (Minutes) 0 - 9
16 - 13 Units (Minutes) 0 - 9
12 - 9 Tenths (Minutes) 0 - 9
8-1 Octal Label 041
1.9 Label 042 - Set Longitude - Input
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 Sign Status Matrix (SSM) Positive = 00
No Computed Data = 01
Functional Test = 10
Negative = 11
29 Undefined Always 0
28 - 25 Tens (Degrees) 0 - 9
24 - 21 Units (Degrees) 0 - 9
20 - 17 Tens (Minutes) 0 - 9
16 - 13 Units (Minutes) 0 - 9
12 - 9 Tenths (Minutes) 0 - 9
8-1 Octal Label 042
1.10 Label 045 - Message Block Start - Input/Output
Refer to Appendix G for a sample FAS data block output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 SSM Normal Operation = 00
No Computed Data = 01
Functional Test = 10
Fail Warning = 11
29 - 27 Spare = 0
26 - 14 Data Block Length (no. of Label
046 to follow)
0 - 8191
13 - 11 Station Slot Identifier Slot Group A = 000 (Note 1)
Slot Group B = 001 (Note 2)
Slot Group C = 010
Slot Group D = 011
Slot Group E = 100
Slot Group F = 101
Slot Group G = 110
34-52-81-1
