INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page C.12
November 21, 2008
1.20 Labels 152 & 167 - Destination and Alternate Waypoint ETA - Input
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 Sign Status Matrix (SSM) Fail Warning = 00
No Computed Data = 01
Functional Test = 10
Normal Operation = 11
29 Reserved Always = 0
28-24 Hours 0-23 hours
23-18 Minutes 0-59 minutes
17 Spare
16 ETA Request Sequence BIT Sequence bit used to distinguish
consecutive requests with same ETA.
15-14 Requesting FMS SDI 00 = Not Defined
01 = FMS 1
10 = FMS 2
11 = FMS 3
13-12 Spare
11 Baro-Corrected Alt. to be
Applied
0 = Baro-Correction not applied
1 = Baro-Correction applied
10-9 Source/Destination Identifier All Call = 00
Unit 1 = 01
Unit 2 = 10
Unit 3 = 11
8-1 Octal Label 135/167 or 152
1.21 Label 156 - Approach Selection Status - Output
ARINC BIT DESCRIPTION SETTING
32 Parity Odd
31-30 Sign Status Matrix (SSM) Normal Operation = 00
No Computed Data = 01
Functional Test = 10
Not Used = 11
29-23 Reserved
= 0
22-21 Approach Request Sequence
Counter
0-3
20 Invalid Approach Valid = 0
Invalid = 1
19 Reserved = 0
18 Invalid FAS Data Block CRC Valid = 0
Invalid = 1
17 Approach Available Not Available = 0
Available = 1
16 Park Status Not Parked = 0
Parked = 1
15 Approach Mismatch No Mismatch = 0
Mismatch = 1
14 Approach Selection
Incomplete
Complete = 0
Incomplete = 1
