INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page A.12
November 21, 2008
Oct.
Label
429 Parameter
Signal
Format
Units
Pos.
Sense
Range (j)
Sig.
Bits
Resolution
(j)
SDI
Used
(n)
Max (a)
Tx Intvl.
125 UTC BCD HR.MIN (b) 23:59:9 5 0.1 MIN No 1200 (f)
126 Flight Phase (h) Packed N/A (b) 0-15 4 N/A No 1200
227(q) Command Summary
Word (h)
Packed N/A N/A N/A N/A N/A Yes Burst /
1200 (p)
260 Date (h) BCD D:M:YR (b) 31:12:99 6 1 day No 1200
301 A/C ID Word (h) Disc N/A N/A N/A N/A N/A No 1200
302 A/C ID Word (h) Disc N/A N/A N/A N/A N/A No 1200
303 A/C ID Word (h) Disc N/A N/A N/A N/A N/A No 1200
Figure A-6. ARINC 429 OMS input bus data labels
Oct.
Label
429 Parameter
Signal
Format
Units
Pos.
Sense
Range (j)
Sig.
Bits
Resolution
(j)
SDI
Used
(n)
Max (a)
Tx Intvl.
272 Weight/Bal Disc (h) Disc N/A N/A N/A N/A N/A No 125
377 Equipment ID (h) N/A N/A N/A N/A N/A N/A No 1200
Figure A-7. ARINC 429 GP/DIFF input bus data labels
Oct.
Label
429 Parameter
Signal
Format
Units
Pos.
Sense
Range (j)
Sig.
Bits
Resolution
(j)
SDI
Used
(n)
Max (a)
Tx Intvl.
201 Data Loader
Command/Data
Coded (k) N/A N/A N/A N/A No N/A
Figure A-8. ARINC 429 Data Loader input bus data labels
Oct.
Label
429 Parameter
Signal
Format
Units
Pos.
Sense
Range (j)
Sig.
Bits
Resolution
(j)
SDI
Used
(n)
Max (a)
Tx Intvl.
017 Selected Runway
Heading (h)
BCD DEG (b) +359.9 4 0.1 No Burst
333 (m)
033 Landing System
Mode/Frequency (h)
BCD N/A N/A N/A N/A N/A Yes Burst
333 (m)
045 Msg Block Start (h)* Block N/A N/A 8192 N/A N/A Yes (l)
046 Msg Block Body (h)* Block N/A N/A N/A N/A N/A Yes (l)
105 Selected Runway
Heading
BNR DEG CW-N ±180 11
≅0.0879
No Burst
333 (m)
227(q) Command Summary
Word (h)
Packed N/A N/A N/A N/A N/A Yes 1200
232 Airport ID #1 (h) DISC N/A N/A N/A N/A N/A Yes Burst (m)
255 Airport ID #2 (h) DISC N/A N/A N/A N/A N/A Yes Burst (m)
Figure A-9. ARINC 429 Freq/Function Data Source input bus data labels
* Proprietary application message format; does not comply with section 7.2.6 of ARINC 755-3
34-52-81-1
